1920 x 1200 at distances up to 50 m/165 ft, 1600 x 1200 at distances up to 200 m/650 ft, 1280 x 1024 at distances up to 300 m/1000 ft.
Up to 300 m/1000 ft. using CATx cable (x=5,5e,6)
Supports computers with USB style keyboard and mice, flat-screen and CRT style monitors with standard HDD-15 video connectors and optional audio through 3.5 mm audio jack.
All known software and operating systems including Windows (all), DOS, Linux, Unix, BSD, Sun OS, Solaris, Mac OS, NetWare etc.
Connectors (USB CAM)
Video: HDD-15 Optional audio: 3.5 mm jack Keyboard, Mouse: USB type A CATx: RJ45 connector
Connectors (X200 remote unit)
Video: HDD-15 Optional audio: 3.5 mm jack Keyboard, Mouse: USB Type A CATx: 2 x RJ45 connector Power: 2.5 mm DC jack
Physical (USB CAM)
Combination of plastic enclosure and cables. Enclosure: 64 mm/2.5 in. x 45 mm/1.8 in. x 25 mm/1 in. Cables: 340 mm/13.4 in. long
Physical (X200 remote unit)
All metal case, 172 mm/6.8 in. x 26 mm/1 in. x 75 mm/3 in. 430 g/1 lb.
100 - 240VAC 50/60Hz (X200 remote unit only)
Order Codes Remote unit only (X200)
X200/R-XX (100 m/330 ft, no audio/de-skew) X200A/R-XX (100 m/330 ft, audio, no de-skew) X200AS/R-XX (300 m/1000 ft, audio/de-skew)
Remote unit (X200) with CAM (computer access module)
X200-USB/P-XX (X200 USB receiver with CATX-USB computer access module) X200A-USB/P-XX (X200A USB receiver with CATX-USBA computer access module) X200AS-USB/P-XX (X200AS USB receiver with CATX-USBA computer access module)
XX= Mains Lead Country Code: UK = United Kingdom US = United States EURO = Europe AUS = Australia
