TP-574 HDMI/ Bidirectional RS-232 and IR over Twisted Pair Receiver by Kramer

SKU: TP-574
TP-574 HDMI/ Bidirectional RS-232 and IR over Twisted Pair Receiver by Kramer

TP-574 HDMI/ Bidirectional RS-232 and IR over Twisted Pair Receiver by Kramer



  • Brand
    Kramer
  • SKU
    TP-574
  • Weight
    1.00 lbs
  • Warranty
    7 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
In stock (50 items available)
The TP-574 is a twisted pair receiver for HDMI, bidirectional RS-232 and infrared signals. The TP-573 converts the input signals to a twisted pair signal and the TP-574 converts it back to HDMI, RS-232 and infrared signals.
  • Brand
    Kramer
  • SKU
    TP-574
  • Weight
    1.00 lbs
  • Warranty
    7 Years
  • Condition
    New
  • Status
    Available
Questions? Ask our experts!

GET A QUOTE




DESCRIPTION

  • The TP-574 is a twisted pair receiver for HDMI, bidirectional RS-232 and infrared signals. The TP-573 converts the input signals to a twisted pair signal and the TP-574 converts it back to HDMI, RS-232 and infrared signals.
    • Max. Data Rate - 1.65Gbps.
    • HDTV Compatible.
    • HDCP Compliant.
    • HDMI Support - HDMI (V.1.4 with Deep Color, x.v.Color™, Lip Sync, HDMI Uncompressed Audio Channels, Dolby TrueHD, DTS-HD).
    • 3D Pass-Through.
    • EDID PassThru - Passes EDID/HDCP signals from source to display.
    • Bidirectional RS-232 & IR Interface. - 38400 max baud rate.
    • System Range - Up to 90m (295ft) at 1080i, or up to 30m (98ft) at 1080p on shielded BC-DGKat524 cable. Up to 90m (295ft) at 1080i, or up to 70m (230ft) at 1080p on shielded BC-DGKat623 cable. Up to 100m (330ft) at 1080i or up to 90m (295ft) at 1080p on shielded BC-DGKat723 cable.
    • Cable - Requires shielded twisted pair (STP) cable. For optimum range and performance use, use Kramer's BC-DGKat524, BC-DGKat623 and BC-DGKat723 cables. Note that the transmission range depends on the signal resolution, graphics card and display used. The distance using non-Kramer CAT 5, CAT 6, and CAT 7 cables may not reach these ranges. Use only shielded cable where both ends of the shield are soldered to ground.
    • Power Connect System™ - A single connection to the transmitter powers both units.
    • Compact DigiTOOLS® - 3 units can be rack mounted side-by-side in a 1U rack space with the optional RK-3T rack adapter.
    Rack Adapters: 19" (1U): RK-3T Compatible Transmitters: TP-573

SPECIFICATIONS

INPUTS: 1 CAT 5 IN on an RJ-45 connector.
OUTPUTS: 1 HDMI connector, 1 bidirectional IR port on a 3.5mm mini jack, 1 bidirectional RS-232 port on a 9-pin D-sub connector.
BANDWIDTH: Supports up to 1.65Gbps bandwidth per graphic channel.
COMPLIANCE WITH HDMI STANDARD: Supports HDMI and HDCP.
POWER SOURCE: 12V DC from TP-573.
DIMENSIONS: 12.1cm x 7.18cm x 2.42cm (4.76" x 2.83" x 0.95"), W, D, H.
WEIGHT: 0.3kg (0.67lbs) approx.
ACCESSORIES: 12V DC power supply.
OPTIONS: RK-3T 19" rack mount, Kramer remote external receiver, Kramer BC DGKat524 (CAT 5 24AWG) and BC DGKat623 (CAT 6 23AWG) cables.
