STD-10K 10 k Ohm Passive Audio Divider-Combiner by RDL

SKU: STD-10K
STD-10K 10 k Ohm Passive Audio Divider-Combiner by RDL

STD-10K 10 k Ohm Passive Audio Divider-Combiner by RDL

  • $88.90
Market price: $98.78, you save $9.88
  • 10% less
Qty:
  • Brand
    RDL
  • SKU
    STD-10K
  • Weight
    0.50 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
In stock (50 items available)
Each STD module is a resistive branching network with RF filtering on each of the four channels. Any channel, A through D, may be either an input or an output. This permits combining stereo signals into mono inputs, splitting mono signals to multiple
  • Brand
    RDL
  • SKU
    STD-10K
  • Weight
    0.50 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
Questions? Ask our experts!

GET A QUOTE
  • $88.90
Market price: $98.78, you save $9.88
  • 10% less


This listing is for STD-10K (10 k Ohm) only. Use description below as a general reference.

Each STD module is a resistive branching network with RF filtering on each of the four channels. Any channel, A through D, may be either an input or an output. This permits combining stereo signals into mono inputs, splitting mono signals to multiple inputs, and even combining microphones with output shorting switches into a single amplifier input. The STD modules are available in 150 O, 600 O and 10 kO models. All inputs and outputs are balanced.

Features:

  • 10 kO Operation
  • Combine Audio Signals to a Single Output
  • Filter RF from an Audio Line
  • Combine Stereo Signals
  • Feed a Mono Signal to Stereo Inputs
  • Combine Multiple Mics to a Single Amp
  • Compactness of RDL STICK-ONs®
Circuit Type: Passive
Circuit Configuration: Balanced
Input/Output Impedance: 10 kO
Number of Inputs/Outputs: 4 total; usable in any combination; split 1 in to 3 out; 2 in to 2 out; 3 in to 1 out
Insertion Loss: 3dB
Isolation Between Channels: 3 dB (use RDL mixers or distribution amps for isolation)
Maximum Signal Input: +22 dBu
Power Requirement: Passive (not required)
Package Type: Cardboard Box
Package Dimensions: 2 x 2 x 4 in.
Shipping Weight: 0.185 lbs.
WEEE weight: 0.135 lbs.
Tariff code: 8518.40.2000
