ST-OSC2A Audio Oscillator/1kHz and 10 kHz by RDL

SKU: ST-OSC2A
ST-OSC2A Audio Oscillator/1kHz and 10 kHz by RDL

ST-OSC2A Audio Oscillator/1kHz and 10 kHz by RDL

  • $147.00
Market price: $163.33, you save $16.33
  • 10% less
Qty:
  • Brand
    RDL
  • SKU
    ST-OSC2A
  • Weight
    1.00 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
In stock (50 items available)
Each of the ST-OSC2 products is a Dual Audio Oscillator. These products are designed for quick, convenient installation, and reliable operation in a variety of audio applications.
  • Brand
    RDL
  • SKU
    ST-OSC2A
  • Weight
    1.00 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
Questions? Ask our experts!

GET A QUOTE
  • $147.00
Market price: $163.33, you save $16.33
  • 10% less


This listing is for ST-OSC2A Oscillator only. Use description below as a general reference.

Each of the ST-OSC2 products is a Dual Audio Oscillator. These products are designed for quick, convenient installation, and reliable operation in a variety of audio applications.

  • Low-impedance output drives virtually any audio line
  • Outputs may be connected to either balanced or unbalanced lines
  • Multiturn level adjustment permits precise output setting
  • Separate output level control provided for each oscillator
  • Integral AGC circuitry for stable output level
  • Each oscillator has two separate outputs to drive stereo lines

The ST-OSC2 products feature RDL's SupplyFlex power input configuration. The module will operate directly from floating 24 Vdc or bipolar dc power. If a jumper is connected between the POWER minus terminal and any module ground, the module power becomes ground-referenced.

Features

  • Precision Sine-Wave Audio Signal
  • Amplitude-Stable Oscillator
  • Two Single-Tone Oscillators
  • 1 kHz and 10 kHz
  • Precise User-Adjustable Levels
  • Each Oscillator Has Two Separate Outputs
  • RDL SupplyFlex Power Input Configuration
Outputs: 2 for each oscillator, bal. or unbal.
Output Impedance: 200 O to drive high or low Z lines
Nominal Frequencies:
ST-OSC2A: 1 kHz and 10 kHz
ST-OSC2B: 100 Hz and 400 Hz
THD+N:
ST-OSC2A: 0,5%
ST-OSC2B: < 3%
Output Level: Off to +10 dBu (adjustable) 600 Q load. Level Maintained by internal AGC circuit
Ambient Operating Environment: 0° C to 55° C
Power Requirement: GROUND-REFERENCED or FLOATING, 24 Vdc @ 80 mA
Package Type: Cardboard Box
Package Dimensions: 2 x 2 x 4 in.
Shipping Weight: 0.2 lbs.
WEEE weight: 0.145 lbs.
Tariff code: 8543.20.0000
