ST-LCR1H 8 Amp High Power Logic Controlled Relay by RDL

SKU: ST-LCR1H
ST-LCR1H 8 Amp High Power Logic Controlled Relay by RDL

ST-LCR1H 8 Amp High Power Logic Controlled Relay by RDL

  • $171.50
Market price: $190.56, you save $19.06
  • 10% less
Qty:
Make an Offer
  • Brand
    RDL
  • SKU
    ST-LCR1H
  • Weight
    1.00 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
888.660.2962 Chat sales@avprosupply.com
In stock (50 items available)
The ST-LCR1H provides dry-switching contacts for high power switching, an LED indicator showing relay activation, and input connections. Switching contacts are suited to switching many 8 Ω, 70.7 V or 100 V speaker lines.
  • Brand
    RDL
  • SKU
    ST-LCR1H
  • Weight
    1.00 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
Product availability status
Questions? Ask our experts!

GET A QUOTE
  • $171.50
Market price: $190.56, you save $19.06
  • 10% less
Make an Offer


The ST-LCR1H provides dry-switching contacts for high power switching, an LED indicator showing relay activation, and input connections. Switching contacts are suited to switching many 8 O, 70.7 V or 100 V speaker lines.

The relay closes when an input signal is applied. The relay releases when the input signal is removed. The ST-LCR1H is ideally suited to applications where high power switching contacts need to be added to nearly any type of control signal. The relay may be activated from any of 3 input signals: 5 Vdc, 24 Vdc, or open-collector.

Use the ST-LCR1H individually, or combine it with other RDL® products as part of a complete audio/video system.

Features:

  • Switching of Speaker Lines
  • Control from Switch or Logic Circuits
  • DPDT Switching Contacts
  • Open-Collector Switching
  • 8 Amp Relay Contacts
Control Inputs: SLAVE terminal used as an input from remote push-button or switch turns on relay when that switch is on. Activation is by connecting this input to Ground. Input from other equipment's open-collector output turns relay on when open-collector is on. Note: RDL switching STICK-ONs® have open-collector outputs suitable for driving an ST-LCR1H.  5V+ accepts 3.5 to 12 Vdc to turn on relay. Relay is on only when this control signal is applied.  24V+ accepts 12 to 35 Vdc to turn on relay. Relay is on only when this control signal is applied.
Control Output: SLAVE terminal open-collector @ 25 mA suitable to drive indicators or slave LCRs
Switching Contacts: Double-pole, double-throw
Max. Current: 8 Amp @ 250 Vac or 30 Vdc
Max. Power: 500 W (Amplified Audio Signal)
Ambient Operating Environment: 0° C to 55° C
Power Requirement: GROUND-REFERENCED. 24 Vdc @ 50 mA
Dimensions: Height: 0.7 in. (1.7 cm), Width: 3 in. (7.6 cm), Depth: 1.6 in. (3.9 cm)
Package Type: Cardboard Box
Package Dimensions: 2 x 2 x 4 in.
Shipping Weight: 0.2 lbs.
V/EES weight: 0.15 lbs.
Tariff code: 8536.49.0050
