SM890i-BK 8in PREMIUM HIGH-SPL SURFACE-MOUNT SPEAKER/88Hz-22kHz/Black by Soundtube

SM890i-BK 8in PREMIUM HIGH-SPL SURFACE-MOUNT SPEAKER/88Hz-22kHz/Black by Soundtube

SKU: SM890i-BK
  • $610.00
Make an Offer
OUT OF STOCK
  • Brand
    Soundtube
  • SKU
    SM890i-BK
  • Weight
    25.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Discontinued
Out of stock
The SM890i is a premium high-SPL, high-efficiency surface-mount loudspeaker for distributed or 8 ohm systems.
  • Brand
    Soundtube
  • SKU
    SM890i-BK
  • Weight
    25.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Discontinued
Product availability status
Questions? Ask our experts!

GET A QUOTE
  • $610.00
Make an Offer


The SM890i is a premium high-SPL, high-efficiency surface-mount loud-speaker for distributed or 8 ohm systems. The SM890i incorporates a dedicated 8-inch treated fiber woofer and a high-power compression horn transducer with a BroadBeamHP® waveguide to deliver a consistent dispersion pattern and superb intelligibility for the foreground music, sound reinforcement and PA markets.

The SM890i uses a 150-watt low-insertion loss transformer and a six-position tap switch with a transformer bypass position. Mounting hardware includes SoundTube’s proprietary tool-free, low profile Stealth™ bracket with an integrated internal wedge cam, which allows for stable and precise aiming from 0 to 90 degrees.

Corrosion-resistant materials, including powder-coated steel grille plus all-aluminum mounting hardware, make the SM890i ideal for indoor/outdoor use

Features

  • Patented BroadBeamHP® waveguide technology delivers a consistent dispersion pattern for maximum intelligibility and edge-to-edge coverage (up to 8 kHz, independently verified).
  • One 8.00 inch (203 mm) treated fiber driver with an offset 1.42 inch (36 mm) compression horn configuration.
  • Engineered with corrosion-resistant materials for indoor/outdoor applications.
  • Proprietary tool-free rotatable 110° x 85° bayonet-mounted horn for tailored dispersion and throw.
  • 150-watt low-insertion loss transformer and maximum output (115 dB max. SPL, 93 dB sensitivity) for short to medium throw, PA and sound reinforcement.
  • Easy-access six-position tap switch for 25/70.7/100-volt applications with transformer bypass position.
  • Powder-coated steel grille with tool-free locking system.
  • Tool-free, low-profile Stealth™ bracket with an integrated internal wedge cam for stable and precise aiming from 0 to 90 degrees. Mounting hardware is constructed of die-cast aluminum.
  • Included pre-mountable pole and surface mount bracket allows for quick and easy division of labor.
  • UL 1480 (UEAY) listed.
  • High-quality black or white paint finish, custom colors optional.
  • Included accessories: Surface-mount bracket, safety cable, paint mask, Euroblock connector, terminal weather boot and paint mask.
System Type 8-inch offset, surface-mount, ported, high power,
(150watt transformer for 25/70.7/100-volt or transformer bypass)
Impedance (nominal)1 8 ohms
Sensiuvity dB @ 2.83 V/l m 93.0 dB
Sensiuvity dB @ 1 W/l m 2 93.0 dB
Frequency Response {- 3 dB) 3 100 Hz-22 kHz
Frequency Response (-10 dB)3 63llz-22kllz
Max. Program Power 4 300 W
Max. Continuous Power RMS 5 150 W
Max. Power SPL @ 1 m 6 115.0 dB
Coverage Angle (-6 dB @ 2 kHz) 110° vertical / 80° horizontal
Coverage Angle (-6 dB @ 10 kHz) 110° vertical / 80° horizontal
Coverage Angle (averaged 2-10 kHz) 110° vertical / 80° horizontal
Angle ot Pointability 0 to 90° horizontal
Directivity Factor (Q) 5.0 (averaged 100 Hz -10 kHz); 8.0 (2 kHz)
Directivity Index (Dl) 5.0 dB (averaged 100 Hz -10 kHz); 8.0 dB (2 kHz)
lap Selector Six-position rotary switch with transformer bypass
Transducer - Lowf requency Driver 203 mm (8.00 in.) treated paper cone with treated cloth surround
Transducer - High-Frequency Driver 36 mm (1.42 in.) titanium compression driver with waveguide
Low-Frequency Voice Coil 34 mm (1.34 in.)
Crossover Frequency 2.5 kHz
Network Type - Low Pass 12 dB per octave, 2nd order
Network Type - High Pass 12 dB per octave, 2nd order
Enclosure Material Injection-molded ABS, glass fiber reinforced
Grille Powder-coated steel
Inputs Four-pin, 5.08 mm Euroblock for indrvidual
or daisy chain connection
Colors Black or white
Height 477.0 mm (18.78 in.)
Width 295.9 mm (11.65 in.)
Depth (including bracket) 390.4 mm (15.37 in.)
Weight 9.5 kg (21.0 lbs.)
Shipping Weight 10.9 kg (24.0 lbs.)
Packaging One per box
Included accessories Surface-mount bracket, safety cable, Euroblock connector,
terminal weather boot and paint mask
Optional accessories N/A
