S-4000R System Remote Control with 9 ft RS-232c Serial Cable by Roland

SKU: S-4000R
S-4000R System Remote Control with 9 ft RS-232c Serial Cable by Roland

S-4000R System Remote Control with 9 ft RS-232c Serial Cable by Roland

  • $395.00
OUT OF STOCK
Make an Offer
  • Brand
    Roland
  • SKU
    S-4000R
  • Weight
    1.00 lbs
  • Warranty
    1 Year
  • Condition
    New
  • Status
    Discontinued
ASK AN EXPERT
Product Questions? Ask Our Experts!
888.660.2962 Chat sales@avprosupply.com
Out of stock
The S-4000R is a component of the S-4000 Digital Snake System. It allows for zipperless remote control of preamp levels for an S-4000S-3208 or any other system source configuration up to 40 channels. It can also switch Phantom Power and Pad settings for individual channels.
  • Brand
    Roland
  • SKU
    S-4000R
  • Weight
    1.00 lbs
  • Warranty
    1 Year
  • Condition
    New
  • Status
    Discontinued
Product availability status
Questions? Ask our experts!

GET A QUOTE
  • $395.00
Make an Offer


The S-4000R is a component of the S-4000 Digital Snake System. It allows for zipperless remote control of preamp levels for an S-4000S-3208 or any other system source configuration up to 40 channels. It can also switch Phantom Power and Pad settings for individual channels. The remote controller can store 9 presets including all of the channel gain and other settings. This allows for fast changes from act to act in a festival and an easy way to return to defaults in an installation.

The S-4000R is typically used at the Front of House console position but can also be used at the Stage position. When a system has two remotes, only one can be active at any time. If the Stage remote is in use, then the FOH unit will be automatically put in a Lock mode. If the FOH operator would like to use the remote, the Lock button is pressed to unlock the remote for use at the FOH position.

The S-4000R is very easy to use. A channel is selected using the channel Dial and then the Gain, Phantom Power and Pad settings can be changed. There is a high res LED Level Meter for the selected channel. There also are indicators showing signal present for each channel. If any channel is clipped, a clip light is shown for that channel and the master Clip button is lit. Pressing the Clip button clears the clip level LEDs. Odd/Even channels can be linked for fast changes to stereo sources.

The S-4000R connects using the provided RS-232c cable. It can be used on top of a console, or rack mounted using the included rack mount kit.

The S-4000R offers a very easy way to control the gain structure and channel settings for an S-4000 Modular Digital Snake, an essential feature of any digital snake system.

Features:

  • Zipperless remote control of channel gain for an S-4000 Modular Digital Snake
  • Controls Channel Gain, Pad and Phantom Power for each individual channel
  • 9 Preset memories of all system settings for fast system setup or return to system default settings
  • Odd/Even channel linking for easy adjustments to stereo sources
  • Signal present and clipping indicator for each channel
  • Hi res selected channel meter display
  • Can be used at FOH location or on Stage
  • Rack mount or table top operation using included 3 meter (~9.5') RS-232c cable

Connector

Remote Connector: 1 (RS-232C, DB-9 type)

Indicators

CLIP Indicators, SIG Indicators, POWER Indicator, REAC Indicator, CTRL Indicator, Level Meter

Power Supply

Supplied from connected device. (S-4000S, S-4000H; through the remote cable)

Operatin Temperature

0 to +40 degrees celsius, +32 to +104 degrees Fahrenheit

Accessories

Remote Cable (3 m), Rack Mount Brackets, Installation Manual
