RU-MX4L Pro 4 Input Line Mixer - Mic and Line Out by RDL

SKU: RU-MX4L
RU-MX4L Pro 4 Input Line Mixer - Mic and Line Out by RDL

RU-MX4L Pro 4 Input Line Mixer - Mic and Line Out by RDL

  • $440.56
Market price: $489.51, you save $48.95
  • 10% less
Qty:
  • Brand
    RDL
  • SKU
    RU-MX4L
  • Weight
    2.00 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
In stock (50 items available)
The RU-MX4L is the ideal choice in many applications where a combination of balanced and/or unbalanced line-level signals needs to be mixed. Balanced connections use XLR connectors. Unbalanced signals are coupled through phono jacks.
  • Brand
    RDL
  • SKU
    RU-MX4L
  • Weight
    2.00 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
Questions? Ask our experts!

GET A QUOTE
  • $440.56
Market price: $489.51, you save $48.95
  • 10% less


The RU-MX4L is the ideal choice in many applications where a combination of balanced and/or unbalanced line-level signals needs to be mixed. Balanced connections use XLR connectors. Unbalanced signals are coupled through phono jacks. Each of the four RU-MX4L inputs can accept either a balanced XLR line-level input or an unbalanced line-level phono jack input. The unbalanced phono jack LINE OUTPUT from one RU-MX4L may connect to the unbalanced input of other equipment, or may be connected to the DIRECT input of another RU-MX4L or an RU-MX4 to expand mixing capabilities. Up to 3 RU-MX4 type mixers may be rack mounted in a single rack unit using an RDL RU-RA3HD rack adapter. The RU-MX4L provides one balanced output, switchable for mic or line level. Audio levels are adjustable on the front panel. Each input channel is equipped with a front-panel dual-LED VU meter that follows standard VU ballistics. The final mix is displayed on an LED string VU meter featuring a visually comfortable arc motion. A factory installed output isolation transformer is available by ordering the RU-MX4LT.

Features

  • Four Channel Line-Level Audio Mixer
  • XLR Balanced, Phono Jack Unbalanced Inputs
  • Mic or Line XLR Output, Switchable
  • Unbalanced Line Output and Direct Input
  • Studio Quality, Low-Noise Performance
  • Expansion Bussing Capability
  • Additional Line Inputs Bussed to an RU-MX4
Balanced Line Inputs(4): 20 kO balanced bridging
Balanced Line Input Level: -13 to +22 dBu for +4 dBu output
Unbalanced Line Inputs (4): 2 kO unbalanced
Unbalanced Line Input Level: -25 dBV tc -20 dBV for -4 dBu output; -10 dBV nominal
Gain Adjustments (4): Balanced Line: Off to 17 dB gain Unbalanced Line: Off to 27 dB gain
Output Attenuator: 0 dB to infinity
Frequency Response: 20 Hz to 30 kHz (± 0.25 dB)
THD+N: < 0.01%
Residual Noise (below +4dBu output): 4 line level sources (unity gain): < -82 dB (wideband)
Outputs (2): +4 dBu 150 ohm balanced (switchable to MIC level -45 dBu); -10 dBV unbalanced
Indicators (17): Dual-LED VU meter for each input; POWER LED; LED audio mix level meter, 0 dB = +4 dBu VU ballistic: -20 dB, -10 dB, -6 dB, -2 dB, 0 dB, +3 dB; Peak reading: +8 dB,+12 dB
Ambient Operating Environment: 0° C to 50° C
Power Requirement: GROUND-REFERENCED, 24 Vdc :S 150 -A,
Package Type: Cardboard Box
Package Dimensions: 6 x 6 x 2.625 in.
Shipping Weight: 1.625 lbs.
WEEE weight: 1.36 lbs.
Tariff code: 8518.40.2000
