PT-5R/T IR Extender and Repeater by Kramer

SKU: PT-5R/T
PT-5R/T IR Extender and Repeater by Kramer

PT-5R/T IR Extender and Repeater by Kramer



  • Brand
    Kramer
  • SKU
    PT-5R/T
  • Weight
    1.00 lbs
  • Warranty
    7 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
In stock (50 items available)
The PT-5T and PT-5R are a twisted pair transmitter and receiver for infrared signals. The units control up to five devices via their own remote control IR transmitters at distances of up to 250m (820ft) over twisted pair cable.
  • Brand
    Kramer
  • SKU
    PT-5R/T
  • Weight
    1.00 lbs
  • Warranty
    7 Years
  • Condition
    New
  • Status
    Available
Questions? Ask our experts!

GET A QUOTE




The PT-5T and PT-5R are a twisted pair transmitter and receiver for infrared signals. The units control up to five devices via their own remote control IR transmitters at distances of up to 250m (820ft) over twisted pair cable.
  • Multi-Unit IR Control - Controls 2 local and 3 remote devices (DVDs, amplifiers, air conditioners, etc.) over their IR ports.
  • Range - Up to 250m (820ft) via twisted pair.
  • Flexible Operation - Operates devices that are stacked away in closets, cabinets and other rooms.
  • PT-5T - Input: 1 IR receiver on a 3.5mm mini jack; outputs: 2 IR emitters on 3.5mm mini jacks; 1 twisted pair on an RJ-45 connector.
  • PT-5R - Input: 1 twisted pair on an RJ-45 connector; outputs: 3 IR emitters on 3.5mm mini jacks.
  • Cable - UTP (unshielded twisted pair) or STP (shielded twisted pair) such as CAT 5.
  • Sold as a Pair.
  • Size - Pico TOOLS™
INPUTS: 1 IR receiver on a 3.5mm mini jack (PT-5T); 1 twisted pair on a RJ-45 connector (PT-5R).
OUTPUTS: 2 IR emitters on 3.5mm mini jacks, 1 twisted pair on a RJ-45 connector (PT-5T); 3 IR emitters on 3.5mm mini jacks (PT-5R).
MAX. OPERATING DISTANCE: 250m (820ft).
OPERATING FREQUENCY: 38kHz.
POWER CONSUMPTION: 5V DC: 7mA (PT-5T), 6mA (PT-5R).
OPERATING TEMPERATURE: 0° to +40°C (32° to 104°F).
STORAGE TEMPERATURE: -40° to +70°C (-40° to 158°F).
HUMIDITY: 10% to 90%, RHL non-condensing.
DIMENSIONS: 5.0cm x 6.6cm x 2.3cm (1.97" x 2.6" x 0.91") W, D, H.
WEIGHT: 0.15kg (0.33lbs) approx.
ACCESSORIES: Power supply, 1 IR receiver with 2m cable and 3.5mm mini jack, 5 IR emitters with 2m cables and 3.5mm mini jacks.
