Micro-Single 3G to HDMI/SDI Scaler/Converter with Stereo Audio Output by Apantac

Micro-Single 3G to HDMI/SDI Scaler/Converter with Stereo Audio Output by Apantac

In stock (50 items available)
Production Quality Compact Video Converter/Scaler. Supports 3G/HD-SD-SDI inputs in 50/60Hz. HDMI and SDI ouput with embeddded audio for monitoring. Supports 8 channels of embedded audio meters. Stereo Analog audio output. Safe Area indicators.
  • Brand
    Apantac
  • SKU
    Micro-Single
  • Weight
    3.00 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
Questions? Ask our experts!

GET A QUOTE
  • $895.00
Qty:


Model: Micro-Single - Production Quality Compact Video Converter/Scaler. Supports 3G/HD-SD-SDI inputs in 50/60Hz. HDMI and SDI ouput with embeddded audio for monitoring. Supports 8 channels of embedded audio meters. Stereo Analog audio output. Safe Area indicators. Dynamic Tally via TSL (IP) or GPI.

Description:

Micro-Single - Production Quality Compact SDI converter/Scaler with HDMI and SDI Output

• Production Quality Compact Video Converter / Scaler
• Turns any inexpensive LCD display into a fully featured Broadcast monitor
• MicroQ based monitor walls companion for PGM/PVW/Full screen monitors
• Supports 3G/HD/SD-SDI Input in 50/60Hz
• HDMI and SDI output with embedded audio for monitoring
• Decodes 8 Embedded Audio with Meters
• Stereo Analog Audio Output
• Safe Area Indicators
• Tally via GPI or dynamic Tally via TSL (IP)
• Front Panel Buttons to recall presets
• IP Control

VIDEO INPUTS

3G/HD/SD-SDI

OUTPUTS

1 x HDMI, 1 SDI

TOTAL WINDOWS

1

HDMI

800x480 to 1920x1200 (1080p) 50/60 Hz

SERIAL DIGITAL

SMPTE 424M, 292M, 259M

SDI

Matching HDMI output resolution up to 3G

Equalization

120m at 2.97 Gbps, 140m at 1.48 Gbps, 400m at

270 Mbps with Belden 1694A

ON-SCREEN DISPLAY

Border, Label, Tally, Safe Area Indicators,

Alarms and Audio Meters

Return Loss

> 15db up to 1.485 Gbps< > 10db up to 3G

GPI

8 for Tally, preset recall or ASCII

Embedded Audio

SMPTE-272M-A

IP

100 Base-Tx, TSL, AXP

ELECTRICAL

12 W, 90-250V 50/60Hz

EMI / RFI

Complies with FCC Part 15, Class A, CE, EU,

EMC, C-tick

POWER

5 DC 3A

SIZE

171 mm W x 120 mm D x 44.45 mm H

MOUNT

Magnetic
