The Aten KL1516AIM 16-Port Cat 5 Dual Rail 17" LCD KVM Over the Net Switch features independently retractable, dual slide 17" LCD monitor and keyboard with built-in touchpad. A single KL1516AIM can control up to 16 computers. For increased reliability and efficiency, RJ-45 connectors and Cat 5e/6 cable are used to link to the computers. Utilizing KVM Adapter Cables for the final linkup, the KL1516AIM permits any combination of Windows computers, Macs, Sun computers, and serial devices to coexist on the installation.
The KL1516AIM features IP-based connectivity that allows local and remote operators to monitor and access the computers on your installation. Because it uses TCP/IP for its communications protocol, it can be accessed from any computer on the LAN, WAN, or Internet, anywhere. KVM console with 17" LCD monitor in a sliding housing with top and bottom clearance for smooth operation in a 1U high rack Dual rail operation - LCD monitor slides independently of the keyboard/touchpad LCD module rotates up to 120° for a more a versatile viewing angle Console lock enables the sliding console to remain securely locked away when not in use A single console controls up to 16 computers - daisy chain up to 31 additional units to control up to 256 computers with compatible KVM switches KVM adapter cables with automatic conversion allow flexible interface combinations. Windows computers, Macs, Sun computers, and serial devices can all coexist on the installation. A dedicated console port for management from an external console - plus an extra PS/2 mouse port for external mouse use with the integrated LCD console No software required - convenient computer selection via port selection switches, hotkeys and intuitive on screen display (OSD) menus OSD screen automatically adjusts to resolution changes - OSD tree structure makes finding and managing computers easy Quickly and conveniently switch to any computer with station and port selection switches - LED displays indicate the station and port location Video settings of attached computers are automatically adjusted for optimal output to the LCD monitor Auto scan feature for monitoring user-selected computers Two level password security - only authorized users view and control the computers - up to four users plus an administrator with separate profiles for each Broadcast support - commands from the keyboard can be broadcast to all available computers on the installation Standard 105-key keyboard; Mac and Sun keyboard emulation Dedicated keys to invoke Hotkey Mode and the OSD from the keyboard for quick access to these functions Rack mountable in 19" system rack (1U) - standard rack mount kit included, easy rack mount optional Keyboard language support: English (US), English (UK), German, German (Swiss), French, Spanish, Traditional Chinese, Japanese, Korean, Swedish, Italian, Russian, Hungarian, Greek Super A-Grade TFT LCD Panel Multiplatform support: Windows 2000/XP/Vista, Mac, Linux, Unix, Sun, FreeBSD Up to 64 user accounts - up to 32 concurrent remote logins End session feature - administrators can terminate any running session Adapter ID - stores port information, allowing administrators to relocate servers to different ports, without having to reconfigure the adapters and switch Port share mode allows multiple users to gain access to a server simultaneously Remote power control for attached Power Over the NET devices Integration with ALTUSEN CC2000 management software Event logging and Windows-based log server support Local log event IPv6 capable Easy computer selection via pushbuttons, hotkey mode, OSD (on screen display), and browser-based GUI Local console, browser, and AP GUIs offer a unified multi language interface to minimize user training time and increase productivity Multi-browser support: Internet Explorer, Chrome, Firefox, Safari, Opera, Mozilla, Netscape Browser-based UI in pure Web technology allows administrators to perform administrative tasks without the need for Java to be pre-installed Panel array mode Keyboard broadcast - keyboard input can be duplicated on all the attached servers (local console only) Remote authentication support: RADIUS, LDAP, LDAPS, and MS Active Directory 128-bit SSL encryption to protect password when users log in Flexible encryption design allows users to choose any combination of 56-bit DES, 168-bit 3DES 256-bit AES, 128-bit RC4, or random for independent KB/mouse, and video data encryption IP/MAC filter support for enhanced security protection Configurable user and group permissions for server access and control Video quality and video tolerance can be adjusted to optimize data transfer speed; monochrome color depth setting, threshold and noise settings for compression of the data bandwidth in low bandwidth situations Full-screen or sizable and scalable virtual remote desktop Message board feature allows logged in users to communicate with each other Mouse DynaSync - automatically synchronizes the local and remote mouse movements On-screen keyboard with multi language support BIOS-level access
