HP590i-BK 5.25in High Power Coaxial Open-Ceiling Speaker/80W/Black by Soundtube

SKU: HP590i-BK
HP590i-BK 5.25in High Power Coaxial Open-Ceiling Speaker/80W/Black by Soundtube

HP590i-BK 5.25in High Power Coaxial Open-Ceiling Speaker/80W/Black by Soundtube

  • $345.00
  • Brand
  • SKU
  • Weight
    23.00 lbs
  • Warranty
    5 Years
  • Condition
  • Status
Product Questions? Ask Our Experts!
Out of stock
The HP590i is a high-powered, 5.25-inch, two-way, horn-loaded loudspeaker in a ported, open-ceiling enclosure design.
  • Brand
  • SKU
  • Weight
    23.00 lbs
  • Warranty
    5 Years
  • Condition
  • Status
Questions? Ask our experts!

  • $345.00

The HP590i is a high-powered, 5.25- inch, two-way, horn-loaded loudspeaker in a ported, open-ceiling enclosure design. The HP590i incorporates a low-profile grille, proprietary motorboard and six-position tap switch with transformer bypass position. Hanging hardware is included and features a SpeedClamp™ self-locking cable grip for fast, easy and secure installation. For indoor/outdoor applications, the HP590i incorporates a powder-coated steel grille, polypropylene driver and durable enclosure design.


  • Patented BroadBeamHP® waveguide technology delivers a consistent dispersion pattern for maximum intelligibility and edge-to-edge coverage (2 to 8 kHz, independently verified).
  • One 5.25 inch (133 mm) polypropylene woofer and one 1.00 inch (25 mm) convex titanium tweeter with a 90º waveguide mounted to a proprietary cast-aluminum baffle and heat sink.
  • Weatherized components for indoor and outdoor applications.
  • Average sensitivity of 87.5 dB offers high output capabilities and reduced amplification costs.
  • Patented ZeroReflection™ enclosure technology for optimal sound reproduction and cabinet rigidity.
  • Easy-access six-position selectable tap switch for 25-, 70.7- and 100-volt applications with transformer bypass position.
  • Includes hanging hardware with galvanized steel cables and integrated SpeedClamp™ self-locking wire grip for fast, easy and secure installation. Also includes Euroblock connector and terminal weather boot.
  • UL 2239 (hanging cable) approved.
  • High-quality black or white paint finish. Custom paint colors optional.
  • Optional accessory: AC-RS-SM5 bracket for surface-mount applications.
System Type 5.25-inch, two-way, high-SPL, open-ceiling, ported (33-watt transformer
for 25/70.7/100-volt or transformer bypass)
Impedance (nominal)1 8 ohms
Sensiuvity dB @ 2.83 V/l m 87.5 dB
Sensiuvity dB @ 1 W/l m? 87.5 dB
Frequency Response {- 3 dB)3 95 Hz - 22 kHz
Frequency Response (-10 dB)3 69 Hz-22 kHz
Max. Program Power' 160 W
Max. Continuous Power RMS5 80 W
Max. Power SPL @ 1 m6 106.5 dB
Coverage Angle (-6 dB @ 2 kHz) 90°
Coverage Angle (-6 dB @ 10 kHz) 55°
Coverage Angle (averaged 2-10 kHz) 85"
Directivity Factor (Q) 5.5 (averaged 100 Hz -10 kHz); 9.1 (2 kHz)
Directivity Index (CH) 5.7 dB (averaged 100 Hz -10 kHz); 9.6 dB (2 kHz)
Tap Selector Six-position rotary switch with transformer bypass
Transducer - Lowf requency Driver 133 mm (5.25 in.) Polypropylene cone, butyl rubber surround
Transducer - High-Frequency Driver 25 mm (1.0 in.) Convex titanium tweeter with tractrix profile horn
Low-Frequency Voice Coil 25.4 mm (1.00 in.)
Crossover Frequency 3.0 kHz
Network Type: Low Pass N/A
Network Type: High Pass 12 dB per octave, 2nd order
Enclosure Material Injection molded ABS, glass fiber reinforced
Grille Steel with powder-coat finish
Inputs Four-pin, 5.08 mm Euroblock for individual or daisy chain connection
Colors Black or white
Height 298.2 mm (11.74 in.)
Diameter 245.9 mm (9.68 in.)
Weight 4.3 kg (9.5 lbs.)
Shipping Weight 10.0 kg (22.0 lbs.)
Packaging Two per box
Included Accessories Hanging hardware, Euroblock connector and terminal weather boot
Optional Accessories Surface-mount bracket (AC-RS-SM5)
Regulatory - UL UL 2239 (hanging cable) approved
Regulatory - CE Approved
RoHS Approved
