HA5-Plus HDMI to 3G-SDI Converter w DSLR format support by AJA

SKU: HA5-Plus
HA5-Plus HDMI to 3G-SDI Converter w DSLR format support by AJA

HA5-Plus HDMI to 3G-SDI Converter w DSLR format support by AJA

  • $505.00
Qty:
Make an Offer
  • Brand
    AJA
  • SKU
    HA5-Plus
  • Weight
    3.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Backordered
ASK AN EXPERT
Product Questions? Ask Our Experts!
888.660.2962 Chat sales@avprosupply.com
In stock (50 items available)
Bring HDMI and 3G-SDI devices together for a full range of monitoring and recording solutions in the edit suite, on set or at live events. Convenient USB setup using AJA MiniConfig on Mac or PC for easy remote configuration.
  • Brand
    AJA
  • SKU
    HA5-Plus
  • Weight
    3.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Backordered
Product availability status
Questions? Ask our experts!

GET A QUOTE
  • $505.00
Make an Offer


Manual

HDMI to 3G-SDI Mini-Converter

HA5-Plus is AJA's next generation HDMI-to-SDI Mini-Converter. The HDMI input is converted to 3G-SDI output for driving SDI monitoring solutions. Up to eight channels of HDMI audio are passed through to the SDI output as well as the ability to embed two channels of analog audio.

Full HDMI Support

The equalized input on HA5-Plus is engineered to support HDMI runs up to 30 meters in length using 24 gauge cable. Embedded HDMI audio support allows for a single cable solution to avoid unnecessary clutter and simplify installation.

Pristine Image Quality

A 3G-SDI output with PLL clock filtering ensures a low jitter output for solid image stability. An LED indicator shows the input source as either SD (green) or HD (red) for fast and easy signal identification.

Analog audio input

Using the two RCA analog audio inputs, embed any 2-channel analog audio signal into the SDI output to maintain proper audio sync throughout the workflow.

DSLR support

HA5-Plus accepts progressive standard definition signals at 525p and 625p for compatibility with DSLR cameras, allowing the signal from those cameras to be easily incorporated into SDI workflows.

USB and MiniConfig Support

AJA's free MiniConfig software can be used with any USB-enabled AJA Mini-Converter and provides an easy-to-use graphical interface with detailed information about the current input and output formats. Control all the parameters of any supported AJA Mini-Converter as well as loading firmware updates from AJA that add new features and functionality.

Universal Power Supply

All AJA Mini-Converters ship with a Universal Power Supply that includes international plug connections for use around the world.

Compact and Portable

AJA Mini-Converters are small enough to fit behind a monitor, in the back of a rack or directly on a camera rig. A locking power connector can't accidentally pull loose and an optional P-TAP power cable allows for battery power in remote locations.

AJA Quality - Guaranteed

All AJA Mini-Converters are covered by a 5-year warranty and AJA's advanced replacement policy. If a replacement is necessary, AJA will ship a new unit immediately without the need to send the original unit back first, ensuring you are up and running again as quickly as possible.

Video Input

  • HDMI with embedded audio, up to 8 channels

Input Formats

  • 525i, 625i, 525p, 625p, 480p, 576p
  • 720p 50, 59.94, 60
  • 1080p 23.98, 24, 25, 29.97, 30, 50, 59.94, 60
  • 1080i 50, 59.94, 60

Note: HDCP content not supported

Video Output

  • 3G-SDI with embedded audio

Output Formats

  • 525i 29.97
  • 625i 25
  • 720p 50, 59.94, 60
  • 1080i 25, 29.97, 30
  • 1080p 23.98, 24, 25, 29.97, 30
  • 1080p 50, 59.94, 60 - SMPTE 425-1 Level A Mapping structure 1 (1920X1080 4:2:2 10-bit YCbCr)

Audio Input

  • 2-channel RCA-style analog audio (-10dBV nominal)

Audio Output

  • SDI embedded audio

Power

  • Uses AJA Power Supply model DWP-U-R1
  • 100-240V, 50/60Hz Universal Input
  • +5V DC regulated, 7.5 watt capacity

Size

  • 4.6' × 2.4' × 1'(117mm × 61mm × 25mm)
