FP-SPR1 SPDIF Repeater/Amplifier by RDL

SKU: FP-SPR1
FP-SPR1 SPDIF Repeater/Amplifier by RDL

FP-SPR1 SPDIF Repeater/Amplifier by RDL

  • $217.94
Market price: $242.16, you save $24.22
  • 10% less
Qty:
  • Brand
    RDL
  • SKU
    FP-SPR1
  • Weight
    1.00 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
In stock (50 items available)
The FP-SPR1 is the ideal product for applications requiring either conversion between SPDIF connector types or recovery of low SPDIF signal levels. Power connections are made using either the full-size barrier block terminals or a dc power jack locat
  • Brand
    RDL
  • SKU
    FP-SPR1
  • Weight
    1.00 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
Questions? Ask our experts!

GET A QUOTE
  • $217.94
Market price: $242.16, you save $24.22
  • 10% less


The FP-SPR1 is the ideal product for applications requiring either conversion between SPDIF connector types or recovery of low SPDIF signal levels. Power connections are made using either the full-size barrier block terminals or a dc power jack located in one end panel. A second dc power jack is provided on the other end panel for connecting additional FLAT-PAK modules.

The FP-SPR1 is a single-channel module featuring three separate inputs. An input is provided in each conventional SPDIF format: BNC, phono and optical. Any one of these inputs may be used. A coaxial input has priority over the optical input. Three output jacks are also provided: BNC, phono and optical. Either of the coaxial jacks may be used and/or the optical output may be connected. It is possible to use only one of the three outputs or use one coaxial and the optical output simultaneously. A front-panel SIGNAL LED illuminates when an input signal of sufficient amplitude is received to produce the correct output from the module.

Features

  • Correct SPDIF Signal Level from Long Line
  • Conversion Between SPDIF Connector Types
  • BNC, Phono and Optical Inputs
  • BNC, Phono and Optical Outputs
  • Reshape SPDIF Waveforms
  • Virtually Jitter-Free Performance
  • Convenience of RDL® FLAT-PAKs™
Inputs (3): 75 O BNC coaxial, 75 O phono coaxial, optical
Input Level: 100 mV to 2.5 V p-p (coaxial)
Outputs (3): 75 O BNC coaxial, 75 O phono coaxial, optical
Output Level: 500 mV p-p (coaxial)
Frequency Range: 28 kHz to 48 kHz
Indicator (1): Signal present LED
Jitter: < 200 pS (input signal 200 mV p-p or greater),
< 1 nS (input signal 100 mV p-p)
Ambient Operating Environment: -10° C to 55° C
Power Requirement: GROUND-REFERENCED, 24 Vdc @ 80 mA Note: May operate from 12 Vdc in standalone installations
Dimensions: Height: 1.34 in. 3.40 cm; Width: 3.25 in. 8.26 cm; Length: 2.82 in. 7.16 cm
Package Type: Cardboard Box
Package Dimensions: 3.625 x 4.625 x 2.125 in.
Shipping Weight: 0.55 lbs.
WEEE weight: 0.375 lbs.
Tariff code: 8518.40.2000
