Description
The IPEL-PE80F-ADW1 is a panoramic turret IP camera designed to capture wide-angle scenes with high clarity. It uses dual 4MP 1/2.7″ CMOS sensors to produce a combined 4096 × 1860 resolution image at up to 20 fps. The camera is engineered for outdoor surveillance applications that require continuous coverage and low-light capability.
Key features include two 2.8mm fixed lenses delivering a 180deg horizontal field of view and Smart Dual Illumination that combines IR and warm white LEDs. The camera offers full-color imaging in low light down to 0.005 lux at F1.4 and can switch to white light for identification when targets are detected. Active deterrence is provided by visible red/blue LEDs and a configurable audio siren to discourage intruders.
Performance details include H.265/H.264 video compression, 3 concurrent streams, and 120 dB WDR for balanced images in high-contrast scenes. Supported resolutions include 4096 × 1860 and multiple scaled outputs for efficient monitoring and recording. The unit also incorporates Intelligent Motion Detect 2.0 and Perimeter Protection for human and vehicle classification to reduce false alarms.
Connectivity and compatibility cover 10/100Base-T Ethernet with PoE (802.3af) and 12 VDC input. The camera supports ONVIF Profile S/G/T and common network protocols for integration with third-party VMS and IC Realtime recorders. Edge storage options include Micro SD up to 256 GB, FTP/SFTP and NAS.
Typical use cases include perimeter surveillance of parking lots, storefront coverage, and wide-area monitoring where a single camera must deliver continuous panoramic coverage. The integrated audio I/O enables two-way communication while active deterrence and smart illumination improve situational response at night. The camera’s analytics assist security teams by prioritizing human and vehicle events for faster review.
Installation and maintenance are straightforward thanks to a turret form factor, IP67 weather rating, and wide operating temperature range. The camera supports PoE for simplified cabling or 12 VDC where required. Built from metal and plastic components with robust mounting adjustments, the IPEL-PE80F-ADW1 is built for reliable outdoor operation and long-term service.
