| Camera | |
| Image Sensor: | 1/2.8" CMOS |
| Effective Pixels: | 1920(H)×1080(V), 2MP |
| Scanning System: | Progressive |
| Minimum Illumination: | 0.002 Lux/F1.6, 30 IRE, 0 Lux IR on |
| Illumination Distance: | Up to 196.9 ft (60m) |
| Illumination On/Off Control: | Auto / Manual |
| Illumination LEDs: | 2 |
| Camera Illumination Type: | IR |
| Lens | |
| Lens Type: | Fixed lens |
| Mount Type: | M12 |
| Focal Length: | 2.8mm |
| Max. Aperture: | F1.6 |
| Angle of View: | 107°; V: 56° |
| Close Focus Distance: | 2.3 ft (0.7m) |
| DORI - Detect: | 144ft |
| DORI - Observe: | 57ft |
| DORI - Recognize: | 28ft |
| DORI - Identify: | 14ft |
| PTZ | |
| OSD Menu: | Multi-language |
| Video | |
| Resolution: | 1080p(1920 × 1080); 960H (960 × 576 / 960 × 480) |
| Frame Rate: | AVS NTSC: 1080p@30 fps; PAL: 1080p@25 fps AHD NTSC: 1080p@30 fps; PAL: 1080p@25 fps TVI NTSC: 1080p@30 fps; PAL: 1080p@25 fps CVBS NTSC: 960 × 480H; PAL: 960 × 576H; |
| Day/Night: | Auto switch by ICR |
| White Balance: | Auto; Area WB |
| Gain Control: | Auto; manual |
| Noise Reduction: | 3D NR |
| WDR: | 130dB |
| Interface | |
| Video Interface: | 1-channel BNC AVS/ TVI/ AHD and CVBS video output (DIP switch) |
| RS485: | N/A |
| Audio I/O: | 1ch in & Built-in Mic |
| Alarm I/O: | N/A |
| Electrical | |
| Power Supply: | 12V DC ±30% |
| Power Consumption: | Max 5.1 W (12V DC, IR on) |
| Environmental | |
| Operating Conditions: | -40°F ~ +140°F (-40°C ~ +60°C ) / Less than 95% RH |
| Storage Conditions: | -40°F ~ +140°F (-40°C ~ +60°C ) / Less than 95% RH |
| Ingress Protection: | IP67 |
| Construction | |
| Casing: | Aluminum |
| Dimensions: | 4.8" × 3.9"(121.9 mm × 99.1 mm) |
| Gross Weight: | 1.37 lb (0.62 kg) |
| Mounting Pan/Tilt/Rotation: | Pan: 0° ~ 360° Tilt: 0° ~ 78° Rotation: 0° ~ 360° |
