| Idle Motion | Configurable time (1–240 minutes); supports preset positions, patrols, scans, and tracks |
|---|---|
| Video | |
| Streaming Capability | 3 Streams |
| Stream / Frame Rate |
Stream 1: 2592×1944, 2592×1520, 1920×1080, 1280×720 @ 25/30 fps Stream 2: D1, VGA, CIF @ 25/30 fps Stream 3: VGA, CIF, QVGA @ 25/30 fps |
| Bit Rate Control | CBR / VBR |
| Bit Rate |
Stream 1: 200 kbps – 16 Mbps Stream 2: 100 kbps – 6 Mbps Stream 3: 100 kbps – 3 Mbps |
| Smart Encoder | Support |
| Region of Interest (ROI) | Support |
| Audio | |
| Audio Compression | G.711, RAW_PCM |
| Audio Bit Rate | 64 kbps (G.711), 128 kbps (RAW_PCM) |
| Image | |
| Image Adjustment | Brightness, Sharpness, Contrast, Saturation |
| Mirror | Support |
| Exposure Mode | Auto / Manual |
| White Balance | Auto / Manual |
| Day/Night Setting | Auto, Day, Night, Time |
| Noise Reduction | 2D / 3D DNR |
| Image Enhancement | HLC, BLC, Defog, Anti-shake |
| Wide Dynamic Range | True WDR |
| S/N Ratio | 50 dB |
| Privacy Masking | Support up to 40 zones, configurable mask color |
| Smart Functions | |
| Basic Events | Motion detection, I/O alarm, disk alarm, network alarm |
| Multi-Object Detection | Face, human, vehicle detection and capture |
| Smoke & Fire Detection | Support |
| Intelligent Analysis | Intrusion, single-line crossing, double-line crossing, loitering, wrong-way detection, illegal parking, smart motion detection (accurate human and vehicle detection) |
| People Counting | Support |
| Smart Tracking | Support |
| Network | |
| Protocols | IPv4, IPv6, TCP/IP, HTTP, HTTPS, RTSP/RTP/RTCP, IGMP/Multicast, SMTP, DHCP, NTP, DNS, DDNS, QoS, SNMP, 802.1X, UDP, ICMP, ARP, TLS |
| Interoperability | ONVIF (Profile S / T / G / M), SDK, CGI |
| Streaming Method | Multicast |
| Max User Access | 10 Users |
| Web Viewer | IE11 and earlier, Chrome, Firefox, Microsoft Edge |
| Language | English, Chinese, Polish, Italian, Portuguese, Spanish, Russian, French, Czech, Hungarian (Default: English) |
| Interface | |
| Network Interface | 1 × Ethernet (10/100 Base-T), RJ-45 |
| Audio Interface | 1-Channel Input, 1-Channel Output |
| Alarm Interface | 7-Channel Input, 2-Channel Output |
| RS-485 | Support |
| CVBS Interface | Support |
| SD Card Slot | Built-in, up to 1 TB |
| Electrical & Physical | |
| Power Supply | 24VAC / 36VDC / PoE++ (802.3bt), Standard: 36VDC |
| Power Consumption | Less than 45 W |
| Operating Temperature | -40°C to 60°C (-40°F to 140°F) |
| Operating Humidity | Less than 90% RH |
| Ingress Protection | IP66, TVS 4000V |
| Certifications | CE / FCC |
| Casing | Metal |
| Dimensions | Ø226 × 362.8 mm (Ø8.9 × 14.28 in) |
| Net Weight | 5.5 kg (12.13 lb) |
