  • nXe8002 Network Power Amplifier 2 x 800 Watts/2 Ohms by Ashly
  • nXe8002 Network Power Amplifier 2 x 800 Watts/2 Ohms by Ashly
nXe8002 Network Power Amplifier 2 x 800 Watts/2 Ohms by Ashly

nXe8002 Network Power Amplifier 2 x 800 Watts/2 Ohms by Ashly

SKU: nXe8002
  • $2399.00
Market price: $2999.00, you save $600.00
  • 20% less
Make an Offer
OUT OF STOCK
  • Brand
    Ashly
  • SKU
    nXe8002
  • Weight
    29.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Backordered
Out of stock
Ashly’s new line of nX Power Amplifiers feature lightweight, energy-efficient Class-D switching amplifier technology combined with a switch mode power supply. nX amplifiers are available in three product families (nX, nXe, nXp) and are designed to
  • Brand
    Ashly
  • SKU
    nXe8002
  • Weight
    29.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Backordered
Product availability status
Questions? Ask our experts!

GET A QUOTE
  • $2399.00
Market price: $2999.00, you save $600.00
  • 20% less
Make an Offer


Manual

This listing is for nXe8002 Amplifier only. Use description below as a general reference.

Ashly’s new line of nX Power Amplifiers feature lightweight, energy-efficient Class-D switching amplifier technology combined with a switch mode power supply. nX amplifiers are available in three product families (nX, nXe, nXp) and are designed to meet the most demanding live sound and fixed installation sound systems in stadiums, arenas, performance venues, worship spaces and convention centers.

The nXe Series is available in either 2 or 4-channel models. Use rear panel DIP switches to program each channel output for either High-Z (70V or 100V Constant Voltage) or Low-Z (stable down to 2 Ohms) operation. When in Sleep Mode, the nX amplifiers draw less than 1 Watt.

nXe is networkable with Ethernet control. It also has serial data control, aux preamp outputs, instant standby mode, preset recall, fault condition logic outputs, and optional network audio and digital audio capability. All controlled using our Protea™ Software Suite.

Features

  • 2 and 4-channel high-output, lightweight amplifiers with programmable output on each channel (High-Z or Low-Z, selected via rear panel DIP switches)
  • Power-saving, Energy Management System‡ (Ashly EMS™) automatic < 1W sleep-mode (defeatable)
  • Front panel power switch and level controls (can be disabled for security)
  • Rear panel DIP switches per channel for selection of high pass filter, limiter, input gain, and High-Z or Low-Z speaker output configuration
  • Remote DC level control on each input channel
  • Switch mode power supply automatically detects 120V or 240V AC operation
  • Extensive protection circuitry, continuously variable cooling fans
  • Multiple independent internal power supplies provide increased channel separation and reliability
  • Ethernet port for use with control and monitoring of amplifier functions, with front panel COM activity LED
  • Serial data port for use with Ashly remote control devices, or optional RS-232 converter for third party controllers (INA-1)
  • Use Protea™ Software to remotely disable all front panel controls, including the on/off switch, for a tamper-proof installation
  • Real-Time Clock with Event Scheduler
  • Instant Standby Mode, 30% reduction in power consumption with on/off triggered by contact closure, software control, or event scheduler
  • Programmable power-on delay
  • Preset recall via contact closure, software control, remote control, or event scheduler
  • Aux preamp outputs, and fault condition logic outputs
  • Optional Cobranet® or Dante® network audio and AES3 digital audio input with pass-through
  • Neutrik® Combo XLR – 1/4” TRS jack plus Euroblock input connectors
  • Neutrik® speakON® twist locking loud- speaker connectors for security, safety, and reliability
  • Neutrik® powerCON® detachable AC mains connector
  3000 & 1500 Watt Models 800 & 400 Watt Models
nXe Series nXe 3.04 nXe 3.02 nXe 1.54 nXe 1.52 nXe 8004 nXe 8002 nXe 4004 nXe 4002
Channels 4 2 4 2 4 2 4 2
*Mox Output Power: Measured in Watts, Per Channel, Low-Z Output, All Channels Driven
2 Ohms 3 000 3 000 1 500 1 500 800 800 400 400
4 Ohms 2 000 2 000 1 500 1 500 800 800 400 400
8 Ohms 1 250 1 250 1 250 1 250 800 800 400 400
*low I Output: Measured in Watts, Bridge Mode, All Channels Driven
4 Ohms 6 000 6 000 3 000 3 000 1 600 1 600 800 800
8 Ohms 4 000 4 000 3 000 3 000 1 600 1 600 800 800
*70V, 100V Output: Measured in Watts, AJI Channels Driven
70V {per channel) 2 450 2 450 1 500 1 500 800 800 400 400
100V {per channel) 1 250 1 250 1 250 1 250 800 800 400 400
Total Power Draw, Measured in Watts, Total for all Channels
Sleep Mode <1 <1 <1 <1 <1 <1 <1 <1
Standby Mode 70 40 70 40 40 25 40 25
Idle (no signal) 100 55 100 55 70 40 70 40
Current Draw: Measured in Amps, Total for all Channels, 120VAC, Divide by 2 for 240V
Sleep Mode 0,1 0,1 0,1 0,1 0,1 0,1 0,1 0,1
Standby Mode 1,30 0,70 1,30 0,70 0,70 0,38 0,70 0,38
Idle (no signal) 1,85 1,00 1,85 1,00 1,30 0,70 1,30 0,70
Max Current Draw: Meosured in Amps, Typical Input, All Channels Driven, Divide by 2 for 240V
XMax Power@20hms 29,5 14,7 16,0 8,0 8,8 4,6 5,0 2,6
Thermal Dissipation: BTUM Typical Input, Total for oH Channels
Sleep mode <3.4 <3.4 <3.4 <3.4 <3.4 <3.4 <3.4 <3.4
Standby mode 238 136 238 136 136 85 136 85
Idle (no signal) 340 187 340 187 238 136 238 136
KMax Power@20hms 2 720 1 360 1 700 850 970 495 595 305

* Measurements based on CEA-2006/490A, 20mS 1kHz 1% THD+N, 480mS 1kHz -20dB.

Specifications Notes: OdBu=0.775 VRMS
Voltage Gain Selectable at 26dB, 32dB, 38d8, or 1.4V
Damping Factor >250 (8 Ohms load <lkHz)
Input High Pass Filter 80Hz 2nd order
Distortion (SMPTE, typical) <0.5%
Distortion (THD-N, typical) <0.5% (8 Ohms, lOdB below rated power, 20Hz-20kHz)
Channel Separation -75dB (dB from full output, 1kHz)
Signal-to-Noise (20Hz-20kHz, unweighted) >114dB (all 3.0x models) >llldB (all 1.5x models) >108dB (all 800x models) >105dB (all 400x models)
Frequency Response 20Hz-20kHz,+/-0.05dB
Balanced Input Connector Euroblock 3.5mm, 1/4' TRS and XLR Combo jack
Input Impedance 10k Ohms
Maximum Input Level +21dBu
Speaker Output Connector Neutrik* speakON*
Control Network Compatible w/ standard 100MB Ethernet
AUX Output Connector Balanced Euroblock 3.5mm
AUX Output Maximum Level +21dBu
Remote Standby Contact Closure Euroblock 3.5mm, close contact to GND for standby mode
Preset Recall Contact Closure Euroblock 3.5mm, close contact to GND for preset 1-4 recall
Data Connection Euroblock 3.5mm - Gnd, +18V, In, Out
Fault Condition Logic Outputs Euroblock 3.5mm - 4 available
Remote DC Level Control Euroblock 3.5mm - Gnd, CV, V+ per input
Attenuators (per channel) Front panel, software, offset link group, and remote. Fully off = Mute
Amplifier Protection Inrush current limitation, temperature monitoring, output over-power protection, mains fuses
Cooling Continuously variable temperature controlled axial fan(s)
Environmental 32-113 deg F, (0-45 deg, C) (noncondensing)
Front Panel LED Indicators
White LED
POWER Switch: On, Off, Standby (flashing)
RedLED
CLIP/MUTE Per Channel: Clip @ ldB below full output / Mute
PROTECT On (fault condition or shut down), Off
Green LED
SIGNAL Per Channel: -18dB below rated output
BRIDGE Per Channel Pair: On, Off
COM On, for Ethernet data or Device ID
CURRENT Per Channel: Proportional to output
Yellow LED
TEMP Per Channel: On dim at 90% max operating temperature, full bright + protect at 100%
SLEEP On, amplifier is asleep from audio inactivity
DISABLE On, power switch & front panel attenuators are disabled
Weights and Dimensions
Unit Weight 1.54/3.04:28.71bs (13kg) 1.52/3.02:22.7lbs (10.3kg) 4002/8002:22.2lbs (10.1kg) 4004/8004:25.9lbs (11.7kg)
Shipping Weight 1.54/3.04:35.2lbs (16kg) 1.52/3.02:29.2lbs (13.3kg) 4002/8002:28.7lbs (13.1kg) 4004/8004:32.4lbs (14.8kg)
Unit Dimensions (all models) 19"W x 3.5"H x 16.84"D (483mm x 89mm x 428mm)
Shipping Dimensions 24.5"W x 22"H x 5.25"D (622mm x 559mm x 133mm)



Power Requirements (@ SO/6OH1)
Nominal (Automatic Sensing SMPS) 120VAC 240VAC
Operating Range 70-135VAC 140-270VAC
Minimum power-up 85VAC 170VAC
Power Cable Connector 20ApowerCON* (32A powerCON* 3.04 model only)
