VS1814T 4-Port HDMI Over Single Cat 5 Splitter by Aten

SKU: VS1814T
VS1814T 4-Port HDMI Over Single Cat 5 Splitter by Aten

VS1814T 4-Port HDMI Over Single Cat 5 Splitter by Aten

  • $1783.00
Qty:
  • Brand
    Aten
  • SKU
    VS1814T
  • Weight
    5.00 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
In stock (50 items available)
The VS1814T HDMI over single Cat 5 Splitter provides a fast and efficient way of switching high definition video from one input source to 4 displays.
  • Brand
    Aten
  • SKU
    VS1814T
  • Weight
    5.00 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
Questions? Ask our experts!

GET A QUOTE
  • $1783.00


The VS1814T HDMI over single Cat 5 Splitter provides a fast and efficient way of switching high definition video from one input source to 4 displays. Incorporating suggested HDBaseT receivers*, the VS1814T can be a complete solution ideal for any installation that requires HDMI content to be delivered to multiple destinations, located up to 100m away from the source.

* Suggested Compatible Receiver Units: VE812R HDMI Over Single Cat 5 Receiver

The solution implements HDBaseT extension technology to connect the VS1814T to receiver units over one single Cat 6 cable in order to transmit rich HDMI multimedia content in real time. It supports up to 4k2k resolution, and features an EDID selection method to ensure constant and reliable EDID data relay for the HDMI source device to efficiently optimize video resolution.

The VS1814T solution is perfect for a wide range of applications:

  • In-store or tradeshow digital signage
  • Information broadcasts at public locations (i.e., news, stations, airline and train schedule and arrival/departure details)
  • Sporting events
  • Theater and lecture overview rooms
  • Classroom and company training facilities

Features

  • One HDMI input to 4HDMI outputs via a Cat 5e cable
  • Offers local HDMI output
  • Extends displays up to 100 m
  • Implements HDBaseT extension technology using only one Cat 5 cable to connect the transmitter and receiver
  • Anti-jamming - resists signal interference during high-quality video transmissions using HDBaseT technology
  • HDMI (3D, Deep color, 4kx2k); HDCP Compatible
  • Supports Dolby True HD and DTS HD Master Audio
  • Consumer Electronics Control (CEC) support
  • Built-in bi-directional RS-232 serial remote port for high-end system control
  • Supports resolutions of up to Ultra HD 4kx2k and 1080p Full HD
  • Supports up to 340MHz bandwidth for high performance video
  • EDID mode selection
  • Rack-mountable

* Note: The VS1814T is compatible with the VE812R HDMIover Single Cat 5 Receiver.

Video Input Interface 1 x HDMI Type A Female (Black)
Impedance 100 ?
Max Distance 1.8 m
Video Output Interface 1 x HDMI Type A Female (Black) - Local Output
4 x RJ-45 Female
Impedance 100 ?
Video Max. Data Rate 10.2 Gbps (3.4 Gbps Per Lane)
Max. Pixel Clock 340 MHz
Compliance HDMI (3D, Deep Color, 4K)
HDCP Compatible
Consumer Electronics Control (CEC)
HDBaseT Compatible
Max Resolutions Up to 4K (Depends on connected receiver)
Max Distance Up to 100 m (Depends on connected receiver)
Audio Input 1 x HDMI Type A Female (Black)
Output 1 x HDMI Type A Female (Black)
Control RS-232 Connector: 1 x DB-9 Female (Black)
Serial Control Pin Configurations:
Pin2 = Tx, Pin 3=Rx, Pin 5= Gnd
Baud Rate and Protocol:
Baud Rate: 19200, Data Bits: 8, Stop Bits:1,
Parity: No, Flow Control: No
EDID Settings EDID Mode: Default / Port 1 / Auto / Learn
Power Connector: 1 x 3-Prong AC Socket (Black)
Consumption:120 VAC, 20W; 230 VAC, 23W
Environment Operating Temp. 0-50°C
Storage Temp. -20 - 60°C
Humidity 0-80% RH, Non-Condensing
Physical
Properties
Housing Metal
Weight 2.10 kg
Dimensions
(L x W x H)
43.24 x 26.11 x 4.40 cm
Carton Lot 1 pcs
