VS-62H 6x2 4K UHD HDMI HDTV/HDCP 3D Matrix Switcher by Kramer

SKU: VS-62H
VS-62H 6x2 4K UHD HDMI HDTV/HDCP 3D Matrix Switcher by Kramer

VS-62H 6x2 4K UHD HDMI HDTV/HDCP 3D Matrix Switcher by Kramer

  • $980.00
Market price: $1225.00, you save $245.00
  • 20% less
Qty:
  • Brand
    Kramer
  • SKU
    VS-62H
  • Weight
    4.00 lbs
  • Warranty
    7 Years
  • Condition
    New
  • Status
    Backordered
ASK AN EXPERT
Product Questions? Ask Our Experts!
In stock (50 items available)
The VS-62H is a high-quality, 6x2 matrix switcher for HDMI signals. It reclocks and equalizes the signals and can route any input to either or both outputs simultaneously
  • Brand
    Kramer
  • SKU
    VS-62H
  • Weight
    4.00 lbs
  • Warranty
    7 Years
  • Condition
    New
  • Status
    Backordered
Questions? Ask our experts!

GET A QUOTE
  • $980.00
Market price: $1225.00, you save $245.00
  • 20% less


The VS-62H is a high-quality, 6x2 matrix switcher for HDMI signals. It reclocks and equalizes the signals and can route any input to either or both outputs simultaneously.

  • Max. Data Rate - 8.91Gbps data rate (2.97Gbps per graphics channel).
  • HDTV Compatible.
  • HDCP Compliant.
  • Max. Resolution - Up to 4K.
  • Kramer reKlocking™ & Equalization Technology - Rebuilds the digital signal to travel longer distances.
  • HDMI Support - 3D, Deep Color, x.v.Color™, Lip Sync, 7.1 multi-channel audio.
  • 3D Pass Through.
  • EDID Capture - Copies and stores the EDID from a display device.
  • Auto Switching Option - For either or both outputs, last-connected or priority switching.
  • Non-Volatile EDID Storage.
  • Lock Button - Prevents unwanted tampering with the front panel.
  • Internal Pattern Generator.
  • Kramer Protocol 3000 Support.
  • Flexible Control Options - Front panel buttons, IR remote (included), optional external remote IR receiver, RS-232, Ethernet, contact closure, embedded Web server.
  • USB Port - For upgrading firmware.
  • Size - Compact Desktop - 2 units can be rack mounted side-by-side in a 1U rack space with the optional RK-1 adapter.

Applications:

  • Conference room presentations
  • Advertising applications
  • Rental and staging
INPUTS: 6 HDMI connectors.
OUTPUTS: 2 HDMI connectors.
PORTS: 1 Ethernet on an RJ-45 connector, 1 IR on a 3.5mm mini jack, 12 remote selection contact-closure switches on 13 terminal block pins, 1 serial port on a 3-pin terminal block, 1 program port on a mini USB connector.
COMPLIANCE WITH HDMI STANDARD: HDMI and HDCP.
RESOLUTION: Up to UXGA; 1080p.
POWER CONSUMPTION: 100-240V AC, 50/60Hz, 21VA.
CONTROLS: Front panel buttons, infrared remote control transmitter, RS-232, Ethernet.
OPERATING TEMPERATURE: 0° to +40°C (32° to 104°F).
STORAGE TEMPERATURE: -40° to +70°C (-40° to 158°F).
HUMIDITY: 10% to 90%, RHL non-condensing.
DIMENSIONS: 19" x 7.24" x 1U (W, D, H).
WEIGHT: 1.6kg (3.53lbs) approx.
INCLUDED ACCESSORIES: Power cord, IR transmitter, rack "ears".
OPTIONS: External remote IR receiver cable.
