VP-558 11x4 HDMI/HDBaseT Presentation Matrix Switcher/Scaler by Kramer

SKU: VP-558
VP-558 11x4 HDMI/HDBaseT Presentation Matrix Switcher/Scaler by Kramer

VP-558 11x4 HDMI/HDBaseT Presentation Matrix Switcher/Scaler by Kramer

  • $5600.00
Market price: $7000.00, you save $1400.00
  • 20% less
Qty:
Make an Offer
  • Brand
    Kramer
  • SKU
    VP-558
  • Weight
    13.00 lbs
  • Warranty
    7 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
888.660.2962 Chat sales@avprosupply.com
In stock (50 items available)
The VP-558 is a high-performance 11x4 ProScale presentation scaler/matrix switcher that can output four independent scaled images.
  • Brand
    Kramer
  • SKU
    VP-558
  • Weight
    13.00 lbs
  • Warranty
    7 Years
  • Condition
    New
  • Status
    Available
Product availability status
Questions? Ask our experts!

GET A QUOTE
  • $5600.00
Market price: $7000.00, you save $1400.00
  • 20% less
Make an Offer


The VP-558 is a high-performance 11x4 ProScale presentation scaler/matrix switcher that can output four independent scaled images. Each output includes an HDMI and HDBaseT connector. The product supports analog, digital and embedded audio. VP-558 features six HDMI inputs, four HDBaseT inputs, an analog VGA input, and a 4x1 USB switcher. VP-558 also includes a microphone input, independent stereo audio outputs, a monitor output, an amplified speaker output, and audio DSP features.

Features

  • Pix-Perfect™ Scaling Technology  - Kramer’s precision pixel mapping and high-quality full up- and down-scaling technology.
  • HDTV Compatible.
  • HDCP Compliant.
  • System Range  - For the HDBT inputs and outputs - up to 70m (230ft).
  • Cables  - For optimum range and performance using HDBaseT™, use Kramer's BC-HDKat6a cable. Note that the transmission range depends on the signal resolution, source and display used. The distance using non-Kramer CAT 6 cable may not reach these ranges.
  • Output Resolutions  - Up to 1080p/UXGA.
  • 4x1 USB Switcher  - Can be set to follow the switching of the video layer or as an independent switcher.
  • OSD (On Screen Display)  - For easy setup and adjustment, accessible via the front panel buttons.
  • Front-panel LCD  - For status display.
  • Audio DSP Features.
  • Input/Output Audio Level Adjustment.
  • Selectable Microphone Talkover or Mix Modes.
  • Analog & Embedded Audio Support  - For inputs and outputs.
  • Built-in Power Amplifier  - 2x10W power amplifier with speaker outputs on a 4-pin terminal block connector.
  • Multiple Aspect Ratio Selections.
  • Built-in ProcAmp  - Color, hue, sharpness, noise, contrast and brightness.
  • Built-in Web Pages  - For easy setup and remote control.
  • Firmware Upgrade via the Ethernet
  • Non-Volatile Memory  - Saves the final settings.
  • Multiple Control Options  - Front panel buttons with OSD, RS-232, Ethernet and built-in Web pages.
  • INPUTS:6 HDMI connectors, 1 VGA on a 15-pin HD connector, 4 HDBT on RJ-45 connectors, 4 USB ports, 6 unbalanced analog audio on 3.5mm mini jacks for HDMI, 1 unbalanced analog audio on a 3.5mm mini jack for PC, 1 aux in/mic balanced stereo audio on a 5-pin terminal block connector.
  • OUTPUTS:4 HDBT on RJ-45 connectors, 4 HDMI connectors, 1 USB port, 4 audio out balanced stereo on 5-pin terminal block connectors, 4 audio out S/PDIF on RCA connectors, monitor out balanced stereo on a 5-pin terminal block connector, monitor out S/PDIF on an RCA connector, 1 stereo speaker output, 2x10W, on a 4-pin terminal block connector.
  • OUTPUT RESOLUTIONS:NATIVE, 640x480@60, 800x600@60, 1024x768@60, 1280x768@60, 1360x768@60, 1280x720@60, 1280x800@60, 1280x1024@60, 1440x900@60, 1400x1050@60, 1680x1050@60, 1600x1200@60, 1920x1080@60, 1920x1200@60, 720x480p@60, 1280x720p@60, 1920x1080i@60, 1920x1080p@60, 720x576p@60, 1280x720p@50, 1920x1080i@50, 1920x1080p@50.
  • CONTROLS:HDMI 1, HDMI 2, HDMI 3, HDMI 4, HDMI 5, HDMI 6, HDBT 1, HDBT 2, HDBT 3, HDBT 4, PC, USB 1, USB 2, USB 3, USB 4 input selector buttons; menu, enter, menu arrows, reset to XGA/720p, OSD SELECT, 2 RS-232, Ethernet, line/mic selector switch, cond/dyn (48V) selector switch, mono/stereo selector switch, REM for muting audio.
  • POWER CONSUMPTION:100-240V AC, 70VA max.
  • OPERATING TEMPERATURE:0° to +40°C (32° to 104°F).
  • STORAGE TEMPERATURE:-40° to +70°C (-40° to 158°F).
  • HUMIDITY:10% to 90%, RHL non-condensing.
  • DIMENSIONS:19" x 14.4" x 2U (W, D, H) rack mountable.
  • WEIGHT:5kg (11lbs) approx.
  • INCLUDED ACCESSORIES:Power cord, rack "ears".
  • OPTIONS:Kramer BC-HDKat6a cable.
