VE170Q VGA/Audio Cat 5 Extender (1024 x 768 300m) by Aten

SKU: VE170Q
VE170Q VGA/Audio Cat 5 Extender (1024 x 768 300m) by Aten

VE170Q VGA/Audio Cat 5 Extender (1024 x 768 300m) by Aten

  • $314.00
Qty:
Make an Offer
  • Brand
    Aten
  • SKU
    VE170Q
  • Weight
    2.00 lbs
  • Warranty
    1 Year
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
888.660.2962 Chat sales@avprosupply.com
In stock (50 items available)
The VE170 A/V Over Cat 5 Extender, comprising of a VE170T Transmitter unit and a VE170R or VE170RQ Receiver unit, is a cost-effective and effi cient solution for sending and receiving high quality audio and video content
  • Brand
    Aten
  • SKU
    VE170Q
  • Weight
    2.00 lbs
  • Warranty
    1 Year
  • Condition
    New
  • Status
    Available
Product availability status
Questions? Ask our experts!

GET A QUOTE
  • $314.00
Make an Offer


The VE170Q package consists of a transmitter (VE170T) and receiver (VE170RQ), which includes ATEN’s patented Deskew™ technology that supports resolutions up to 1280 x 1024 @ 300 m, and features manual synchronization of the RGB signals and correction of color phase and timing errors that occur over long distances.

The VE170Q VGA / Audio Cat 5 Extenders provides a flexible solution which is ideal for any professional A/V installation that requires multimedia content to be delivered over a long distance.

Features
  • Connects a transmitter and receiver via Cat 5e cable
  • Supports one local and one remote VGA display
  • Long distance transmissions – up to 300 m
  • Deskew™ – automatically synchronizes the time delay of RGB signals to compensate for distance
  • Adjustable Gain Control – signal strength can be manually adjusted via video gain or video compensation tuners
  • Audio supported (mono)
  • Built-in ESD protection
  • Rack-mountable
Video Input
Interfaces N/A 1 x HDB-15 Male (Blue)
Impedance N/A 75 Ώ
Max. Distance N/A 1.8 m
Video Output
Interfaces 1 x HDB-15 Female (Blue) 1 x HDB-15 Female (Blue)
Impedance 75 ohm 75 ohm
Video
Max. Bandwidth 300 MHz 300 MHz
Max. Resolutions / Distance Up to 1920 x 1200@30m; 1024 x 768@300m Up to 1920 x 1200@30m; 1024 x 768@300m
Audio
Input N/A 1 x Mini Stereo Jack Female (Green)
Output 1 x Mini Stereo Jack Female (Green) 1 x Mini Stereo Jack Female (Green)
Power
Connectors 1 x DC Jack 1 x DC Jack
Consumption 5.3 VDC, 1.11W 5.3 VDC, 0.9W
Environmental
Operating Temperature 0-50°C 0-50°C
Storage Temperature -20 - 60°C -20 - 60°C
Humidity 0 - 80% RH, Non-Condensing 0 - 80% RH, Non-Condensing
Physical Properties
Housing Metal Metal
Weight 0.24 kg ( 0.53 lb ) 0.24 kg ( 0.53 lb )
Dimensions (L x W x H) 12.77 x 9.04 x 2.26 cm (5.03 x 3.56 x 0.89 in.) 12.77 x 9.04 x 2.26 cm (5.03 x 3.56 x 0.89 in.)
Carton Lot 5 pcs 5 pcs
