TX-TPS6A Passive 1-Pair Extender (Transmitter)/Format-A/balanced line output by RDL

SKU: TX-TPS6A
TX-TPS6A Passive 1-Pair Extender (Transmitter)/Format-A/balanced line output by RDL

TX-TPS6A Passive 1-Pair Extender (Transmitter)/Format-A/balanced line output by RDL

  • $132.40
Market price: $147.11, you save $14.71
  • 10% less
Qty:
Make an Offer
  • Brand
    RDL
  • SKU
    TX-TPS6A
  • Weight
    1.00 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
888.660.2962 Chat sales@avprosupply.com
In stock (50 items available)
The TX-TPS6A is a single-pair audio sending module compatible with RDL Format-A twisted pair products. One low-impedance +4 dBu balanced line-level audio source connects to the module using the detachable terminal block. A studio-quality transformer
  • Brand
    RDL
  • SKU
    TX-TPS6A
  • Weight
    1.00 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
Product availability status
Questions? Ask our experts!

GET A QUOTE
  • $132.40
Market price: $147.11, you save $14.71
  • 10% less
Make an Offer


The TX-TPS6A is a single-pair audio sending module compatible with RDL Format-A twisted pair products. One low-impedance +4 dBu balanced line-level audio source connects to the module using the detachable terminal block. A studio-quality transformer provides isolation between the audio source and the RJ45 OUTPUT.

The TX-TPS6A is a single-pair sender, feeding the input signal to the cable pair set on the front-panel switch during installation. This module drives only one cable pair, therefore a LOOP IN RJ45 jack is provided to accept signals and power from other mic-level or line-level Format-A senders. Two other single-pair senders may be chained to the LOOP IN jack, or a single two-pair sender may be connected. If three single-pair senders are connected together, each sender must feed a different pair: A, B or C. The TX-TPS6A must be set to feed pair A if it is connected together with an RDL two-pair sender that feeds stereo audio on pairs B and C.

The TX-TPS6A is a passive module that does not require power to operate. If power is present on a cable connected to the LOOP IN jack, that power is passed through to the modules connected to the OUTPUT jack.

Features

  • Single +4 dBu Low-Impedance Balanced Audio Input
  • Input on Detachable Terminal Block
  • Switch Selects which RJ45 Pair (A, B or C) is Fed
  • Signal and Power Pair Pass-Through from LOOP IN Jack
  • Passive Circuitry Does Not Require Power
  • Galvanic Isolation through a Studio-Quality Transformer
  • Daisy-Chain with Single-Pair or Two-Pair Format-A Senders
Input: Low- impedance Balanced; Recommended source impedance < 150 O
Input Connection: Detachable Terminal Block (Balanced)
Input Level: +4 dBu balanced; +22 dBu Max
Format- A Signal Pair Used: Switch-selectable A, B, or C
Format-A Input: RJ45 LOOP IN
Output: RDL TP Format-A
Output Connection: RJ45
Frequency Response: 20 Hz to 20 kHz (± 0.1 dB)
THD+N: < 0.035% (50 Hz to 20 kHz, +4 dBu); < 0.1% (20 Hz to 20 kHz, + 4 dBu)
Headroom above +4 dBu: > 18 dB
CMRR: > 85 dB (50 Hz to 150 Hz)
Ambient Operating Environment: 0° C to 50° C
Power Requirement: Passive
Dimensions: 3.0" (7.6 cm) W; 1.6" (4.08 cm) H; 2.09" (5.3 cm) D
Package Type: Cardboard Box
Package Dimensions: 2 x 2 x 4 in.
Shipping Weight: 0.89 lbs.
WEEE weight: 0.74 lbs.
Tariff code: 8517.18.0000
