TM-360 60W 3-Input Mixer/Amplifier with XFMR Isolated Constant-Voltage/4 Ohm Out by Ashly

SKU: TM-360
  • TM-360 60W 3-Input Mixer/Amplifier with XFMR Isolated Constant-Voltage/4 Ohm Out by Ashly
  • TM-360 60W 3-Input Mixer/Amplifier with XFMR Isolated Constant-Voltage/4 Ohm Out by Ashly
TM-360 60W 3-Input Mixer/Amplifier with XFMR Isolated Constant-Voltage/4 Ohm Out by Ashly

TM-360 60W 3-Input Mixer/Amplifier with XFMR Isolated Constant-Voltage/4 Ohm Out by Ashly

  • $449.00
Market price: $549.00, you save $100.00
  • 18% less
OUT OF STOCK
Make an Offer
  • Brand
    Ashly
  • SKU
    TM-360
  • Weight
    10.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
888.660.2962 Chat sales@avprosupply.com
Out of stock
The TM Series of compact tabletop mixer/amplifiers are the products of choice in small restaurants, retail stores, bistros, convenience stores and mini-marts and school classrooms.
  • Brand
    Ashly
  • SKU
    TM-360
  • Weight
    10.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Available
Product availability status
Questions? Ask our experts!

GET A QUOTE
  • $449.00
Market price: $549.00, you save $100.00
  • 18% less
Make an Offer


Manual

The TM-360 is a 3-input, 60W unit that offers input and output flexibility coupled with energy efficiency. It uses a Class-D amplifier topology for added energy efficiency.

A front panel 3.5mm TRS mini-jack makes it easy to plug-in a back-up music source, such as an mp3 player. Rear panel DIP switches allow you to select the mix going to each zone. There are 2 separate zone outputs: a 1W output for driving a remote speaker, and a preamp output that can be used to drive a separate amplifier.

The TM-360 automatically switches into a stand-by mode if no audio input is received for 25 minutes, thus reducing the current draw. The transformer-isolated output offers a choice of lo-z (4 Ohm), 25V or 70V.

Features

  • One balanced mic/line input with phantom power, 2 balanced line level inputs with stereo RCA sum-to-mono inputs
  • Mute priority of inputs
  • Manual mute contact closure
  • Mini-jack input on front panel overrides channel 2-input on back
  • DIP switches for zone 2 assign vox trigger, mute priority, low-cut filter, phantom power
  • 600 Ohm pre-out for external amplifier
  • Zone 2-output, 1W / 8 Ohms, Balanced 600 Ohm
  • Power saving standby mode: audio inactivity or contact closure
  • Optional rack mount kit (model RMK-360)
  • Safety/Compliance: cCSAus, CE FCC, RoHS
Total Harmonic Distortion
60W (@ 1kHz) <1%
Frequency Response: 1W @ 1kHz
Input 1,2,3 +l/-3dB,80Hz-15kHz
Tone Control
Bass(lOOHz) +-l0dB
Treble (10kHz) +-l0dB
Input Sensitivity
Input 1 -10dBVto-50dBV
Input 2,3_ 0dBV to -20dBV_
Signol-to-Noise Ratio: 60W @ 1kHz, A-weighted
Input 1,2,3 >S0dB
Residual Noise: Input 1-3 Volume Min, Tone Set (S> Center
Master Volume (Min) -72dB
Master Volume (Max) -57dB
Zone 2 Output
Rated Power (8 Ohm) 1W \1% THD)
Balanced (600 Ohm)
Mix Configuration Switches
SW1 Zone 2 Assign Input 1
SW2 Zone 2 Assign Input 2
SW3 Zone 2 Assign Input 3
SW4 VOX Trigger Input 1
SW5 VOX Trigger Input 2
SW6 MuteLinklnput2&3
SW7 Low Cut, 400Hz 6dB/Oct
SW8 Chi Phantom Power, +18V
Contact Closure
Manual Mute Pins 1 & G = Input 1 Mute Trigger
Master System Standby Pins G + 2 Power Standby

TM Model                      Note:OdBV = lV TM-360
Channels 3
Signal-to-Noise (26d8 Gain) 80dB
Max Output Power: 1% THD
4 Ohms 60W
8 Ohms 30W
Constant Voltage Power: 1% THD
25V 60W
70V 60W
Line Current Draw: § 120VAC 60Hz (Divide values by2for230VAC)
Standby Mode 0.15A
Idle 0.24A
Typical (1/8 power pink noise) 0.38A
Max (1/3 power sine wave) 0.66A
Thermal Dissipation: BTU/hr
Standby Mode 26
Idle 43
Typical (1/8 power pink noise) 53
Max (1/3 power sine wave) 75
