ST-MA2 Muting Monitor Amplifier - 2 Watt by RDL

SKU: ST-MA2
ST-MA2 Muting Monitor Amplifier - 2 Watt by RDL

ST-MA2 Muting Monitor Amplifier - 2 Watt by RDL

  • $133.70
Market price: $148.56, you save $14.86
  • 10% less
Qty:
Make an Offer
  • Brand
    RDL
  • SKU
    ST-MA2
  • Weight
    0.50 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
888.660.2962 Chat sales@avprosupply.com
In stock (50 items available)
The ST-MA2 is a compact audio monitor amplifier with control inputs to mute or reduce the gain of its output. This module may be used in conjunction with other RDL® modules to configure automatic mixing systems or may be used alone as a single-speake
  • Brand
    RDL
  • SKU
    ST-MA2
  • Weight
    0.50 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
Product availability status
Questions? Ask our experts!

GET A QUOTE
  • $133.70
Market price: $148.56, you save $14.86
  • 10% less
Make an Offer


The ST-MA2 is a compact audio monitor amplifier with control inputs to mute or reduce the gain of its output. This module may be used in conjunction with other RDL® modules to configure automatic mixing systems or may be used alone as a single-speaker monitor amplifier. The ST-MA2 is typically used to drive a small tabletop or overhead monitor speaker in a conference room, boardroom, courtroom, public forum panel or similar installation. The ST-MA2 is ideally suited for use in automatic mixing systems due to its control inputs.

The line-level input may be wired balanced or unbalanced. The audio output will drive standard speakers from 4 to 45 O. Normal gain is preset by means of a trimmer on the module.

For tabletop installations, use the ST-MA2 with the WDG1 and RU-SP1.

Features

  • Single-Speaker Monitor Amplifier
  • Conferencing Monitor Amp
  • Monitor Amp with Muting and Externally Actuated Attenuation Steps
  • Fast, Silent Audio Switching
  • Multiple Control Inputs
  • Adjustable Gain
Input Impedance: 20 kO Balanced or Unbalanced Bridging
Input Level: -10 dBV minimum for 2 Watts RMS output
Output Impedance: 8 O (will drive 4 O loads)
Output Power: 1.75 Watts RMS Continuous; 2 Watts RMS max.
THD+N: < 0.5%
Bandwidth: 45 Hz to 14 kHz
CMRR: > 60 dB (50 Hz to 120 Hz)
Residual Noise: < -80 dB (below 2 Watts RMS)
Switching Time: < 50 us
Attenuation (Muted): > 90 dB (1 kHz), > 85 dB (300 Hz to 3 kHz) > 75 dB (20 Hz to 20 kHz)
Selectable Attenuation: 3 dB or 6 dB, each setting individually selectable using two independent inputs (connect to ground to activate, 0.3 mA)
Ambient Operating Environment: 0° C to 40° C
Power Requirement: GROUND-REFERENCED, 24 Vdc @ 200 mA for rated output (220 mA @ 2 Watts RMS)
Package Type: Cardboard Box
Package Dimensions: 2 x 2 x 4 in.
Shipping Weight: 0.195 lbs.
WEEE weight: 0.145 lbs.
Tariff code: 8518.40.2000
