ST-HP3 300 Hz and 500 Hz High Pass Filter by RDL

SKU: ST-HP3
ST-HP3 300 Hz and 500 Hz High Pass Filter by RDL

ST-HP3 300 Hz and 500 Hz High Pass Filter by RDL

  • $193.09
Market price: $214.54, you save $21.45
  • 10% less
Qty:
Make an Offer
  • Brand
    RDL
  • SKU
    ST-HP3
  • Weight
    1.00 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
888.660.2962 Chat sales@avprosupply.com
In stock (50 items available)
The ST-HP3 is the ideal choice where line-level audio filtering needs to be provided at the input of a power amplifier for protection of public address horns against damage from low frequencies.
  • Brand
    RDL
  • SKU
    ST-HP3
  • Weight
    1.00 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
Product availability status
Questions? Ask our experts!

GET A QUOTE
  • $193.09
Market price: $214.54, you save $21.45
  • 10% less
Make an Offer


The ST-HP3 is the ideal choice where line-level audio filtering needs to be provided at the input of a power amplifier for protection of public address horns against damage from low frequencies.

The ST-HP3 has one input and two filtered outputs: 300 Hz high pass and 500 Hz high pass. Both the input and output are balanced, and each may be wired unbalanced if required. The input accepts line-level (+4 dBu nominal) audio. The module operates at unity gain (balanced input and output). The two outputs may be used simultaneously.

The ST-HP3 features RDL's SupplyFlex power input configuration for operation directly from ground-referenced, floating or bipolar 24 Vdc power.

Features:

  • Horn Loudspeaker Protection
  • Low-Frequency Attenuation below 300 Hz
  • Low-Frequency Attenuation below 500 Hz
  • Line-Level Input and Outputs
  • Filtering Requiring no Field Adjustment
  • RDL® SupplyFlex™ Power Input Configuration
Input: 20 kO balanced line level (+4 dBu)
Outputs (2): 150 O balanced line level (+4 dBu)
Headroom: > 18 dB
Attenuation Curve: 18 dB/octave
THD+N: < 0.01%
Residual Noise: < 90 dB (referred to +4 dBu)
Insertion Loss: < 2dB
300 Hz Output: Frequency Response: 300 Hz to 30 kHz (± 0.5 dB); -3 dB Frequency: 225 Hz
500 Hz Output Frequency Response: 500 Hz to 30 kHz (± 1.0 dB); -3 dB Frequency: 450 Hz
Ambient Operating Environment: 0° C to 55° C
Power Requirement: GROUND-REFERENCED or FLOATING, 24 Vdc @ 30 mA
Dimensions: Height: 0.7 in. (1.7 cm), Width: 3 in. (7.6 cm), Depth: 1.6 in. (3.9 cm)
Package Type: Cardboard Box
Package Dimensions: 2 x 2 x 4 in.
Shipping Weight: 0.19 lbs.
WEEE weight: 0.14 lbs.
Tariff code: 8518.40.2000
