ST-EQ3 Line Level 3-Band Extender Equalizer by RDL

SKU: ST-EQ3
ST-EQ3 Line Level 3-Band Extender Equalizer by RDL

ST-EQ3 Line Level 3-Band Extender Equalizer by RDL

  • $153.60
Market price: $170.67, you save $17.07
  • 10% less
Qty:
  • Brand
    RDL
  • SKU
    ST-EQ3
  • Weight
    0.50 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
In stock (50 items available)
The ST-EQ3 features a balanced bridging input, which may be connected unbalanced if desired. The output driver is 150 Ω balanced, and is intended to drive unbalanced or balanced lines of 150 Ω or higher impedance. Equalization is accomplished by thre
  • Brand
    RDL
  • SKU
    ST-EQ3
  • Weight
    0.50 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
Questions? Ask our experts!

GET A QUOTE
  • $153.60
Market price: $170.67, you save $17.07
  • 10% less


The ST-EQ3 features a balanced bridging input, which may be connected unbalanced if desired. The output driver is 150 O balanced, and is intended to drive unbalanced or balanced lines of 150 O or higher impedance. Equalization is accomplished by three active circuits, each controlling a separate audio band. These bands were carefully selected to yield a module that works effectively in a wide variety of systems. Setup of the ST-EQ3 is assisted by a peak overload LED which indicates excessive pre or post EQ levels.

Features:

  • 3-Band Audio Equalization
  • Custom Tailored Audio Bandwidth
  • Adjust To Pass Voice-Band Audio
  • Adjust To Produce Smile-Curve for Music
  • Low Noise and Low Distortion Equalization
Input: 100 kO balanced or unbalanced bridging; line-level
Gain: OFF to unity (adjustable, ± EQ adjustment)
Audio Output: + 4 dBu nominal, 150 O balanced
THD+N: < 0.030%; 0.010% typical (1 kHz flat response)
CMRR: > 60 dB (50 to 120 Hz)
Frequency Response: 20 Hz to 22 kHz (EQ set flat; ± 0.5 dB), into 600 O; 10 Hz to 22 kHz (EQ set flat; ± 0.5 dB), into bridging load
Noise: < -80 dB (below +4 dBu)
Center Frequencies: LOW Band: 80 Hz MID Band: 1 kHz HIGH Band: 30 kHz
Bandwidth at 3dB EQ: LOW Band: 20 Hz to 300 Hz MID Band: 200 Hz to 7 kHz HIGH Band: 3 kHz to 30 kHz
Ambient Operating Environment: 0° C to 55° C
Power Requirement: GROUND-REFERENCED, 24 Vdc @ 25 mA
Dimensions: Height: 0.7 in. (1.7 cm), Width: 3 in. (7.6 cm), Depth: 1.6 in. (3.9 cm)
Package Type: Cardboard Box
Package Dimensions: 2 x 2 x 4 in.
Shipping Weight: 0.17 lbs.
WEEE weight: 0.12 lbs.
Tariff code: 8518.40.2000
