SM500i-II-BK 5.25in COAXIAL SURFACE MOUNT SPEAKER/86 Hz-22 kHz/Black by Soundtube

SKU: SM500i-II-BK
SM500i-II-BK 5.25in COAXIAL SURFACE MOUNT SPEAKER/86 Hz-22 kHz/Black by Soundtube

SM500i-II-BK 5.25in COAXIAL SURFACE MOUNT SPEAKER/86 Hz-22 kHz/Black by Soundtube
OUT OF STOCK
Make an Offer
  • Brand
    Soundtube
  • SKU
    SM500i-II-BK
  • Weight
    11.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Discontinued
ASK AN EXPERT
Product Questions? Ask Our Experts!
888.660.2962 Chat sales@avprosupply.com
Out of stock
The SM500i-II is a 5.25-inch, two-waysurface-mount speaker with a midsizeenclosure design that delivers effectivelow-end response (60 Hz) and optimal off-axis performance (2 to 10 kHz).
  • Brand
    Soundtube
  • SKU
    SM500i-II-BK
  • Weight
    11.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Discontinued
Product availability status
Questions? Ask our experts!

GET A QUOTE
Make an Offer




Manual

The SM500i-II is a 5.25-inch, two-way surface-mount speaker with a midsize enclosure design that delivers effective low-end response (60 Hz) and optimal off-axis performance (2 to 10 kHz). SoundTube’s proprietary BroadBeam® waveguide tweeter system delivers consistent high-performance audio across operating bandwidth.

The SM500i-II speaker design incorporates a low-profile grille, six-position tap switch with transformer bypass and mounting hardware, including the Stealth™ bracket mounting system. The SM500i-II incorporates a security knob to reduce tampering after placement, unlimited directional aiming, and a low profile.

Features

  • BroadBeam® waveguide technology delivers a consistent dispersion pattern up to 10 kHz for maximum coverage area per speaker.
  • One 5.25 inch (133 mm) polypropylene woofer and one 1.0 inch (25 mm) convex titanium tweeter with FerroFluid™ cooling.
  • 86.0 dB average sensitivity offers high output capabilities and reduced amplification costs.
  • Includes stainless steel screws and weatherized components for indoor and outdoor applications (SM500i-II-WX available for severe weather installations).
  • Easy access, six-position selectable tap switch for 25-, 70.7- and 100-volt applications with transformer bypass position.
  • Patented ZeroReflection™ enclosure technology for optimal sound reproduction and cabinet rigidity.
  • Aluminum grille with powder-coat finish
  • Includes the new SM500i-II Stealth™ bracket mounting system.
  • Vertical and horizontal pivoting allow the SM500i-II to be aimed anywhere within the installation space.
  • Low profile enclosure design keeps the speaker close to the wall.
  • UL 1480 (UEAY) planned.
  • High-quality black or white paint finish.
  • Included Accessories: Safety cable with speaker mounting bolt, Euroblock con?nector, wall mount bracket and terminal weather boot
System Type 5.25-inch, coaxial, surface-mount, ported (64-watt transformer
for 25/70.7/100-volt or transformer bypass)
Impedance (Nominal)! 4 ohm
Sensitivity dB@ 2.83V/1 M 86.0 dB
Sensitivity dB @ 1 W/l M 2 83.0 dB
Frequency Response (-3 dB)3 86 Hz-22 kHz
Frequnecy Response (-10 dB)3 60 Hz - 22 kHz
Max. Program Power4 150W
Max. Continuous Power RMS5 75 W
Max. SPL dB @ 1 M RMS 6 102 dB
Coverage Angle (-6 dB @ 2 kHz) 75° horizontal / 90° vertical
Coverage Angle (-6 dB @ 10 kHz) 120° horizontal / 125° vertical
Coverage Angle (Avg. 2 to 10 kHz) 100° horizontal / 100° vertical
Aiming Angle (radial) 360°
Aiming Angle (horizontal) 0-90°
Directivity Factor (Q) 4.6 (Averaged 100 Hz -10 kHz); 9.8 @ 2 kHz
Directivity Index (Dl) 5.6 dB (Averaged 100 Hz -10 kHz); 9.9 dB @ 2 kHz
Tap Selector Six-position rotary switch with transformer bypass
Low-Frequency Driver 1 x 133 mm (5.25 in) polypropylene cone, butyl rubber surround
High-Frequency Driver 25 mm (1.0 in ) convex titanium tweeter with waveguide
Low-Frequency Voice Coil 25 mm (1.0 in)
Crossover Frequency 3 kHz
Network Type: Low-Pass 12 dB per octave, 2nd order
Network Type: High-Pass 12 dB per octave, 2nd order
Enclosure Material Injection-molded ABS, glass fiber reinforced
Grille Aluminum with powder-coat finish
Inputs Four-pin, 5.08 mm Euroblock for individual or daisy chain
  connection
Colors Black or white (Custom colors available)
Height 289.56 mm (11.40 in)
Width 212.26 mm (8.36 in)
Depth (Including Bracket) 266.30 mm (10.48 in)
Weight 4.3 kg (9.5 lbs)
Shipping Weight 5.0 kg (11 lbs)
Included Accessories Safety cable with speaker mounting bolt, Euroblock
connector, wall mount bracket and terminal weather boot
Optional Accesso-ies N/A
