RS500i-BK 5.25in Coaxial Open-Ceiling Speaker/8 Ohm/87 Hz-22 kHz/Black by Soundtube

SKU: RS500i-BK
RS500i-BK 5.25in Coaxial Open-Ceiling Speaker/8 Ohm/87 Hz-22 kHz/Black by Soundtube

RS500i-BK 5.25in Coaxial Open-Ceiling Speaker/8 Ohm/87 Hz-22 kHz/Black by Soundtube

  • $320.00
Qty:
  • Brand
    Soundtube
  • SKU
    RS500i-BK
  • Weight
    23.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
In stock (50 items available)
The RS500i is a 5.25-inch, two-way, ported speaker with an open-ceiling enclosure design that delivers effective low-end response (61 Hz) and 105º offaxis performance (2 to 10 kHz, independently verified)
  • Brand
    Soundtube
  • SKU
    RS500i-BK
  • Weight
    23.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Available
Questions? Ask our experts!

GET A QUOTE
  • $320.00


The RS500i is a 5.25-inch, two-way, ported speaker with an open-ceiling enclosure design that delivers effective low-end response (61 Hz) and 105º offaxis performance (2 to 10 kHz, independently verified). SoundTube’s proprietary BroadBeam® waveguide tweeter system delivers consistent high-performance audio coverage across the operating bandwidth. The RS500i speaker design incorporates a low-profile grille, proprietary motor-board and a six-position tap switch with transformer bypass position. Hanging hardware is included and features SpeedClamp™ self-locking wire grip for fast, easy and secure installation.

Features

  • Patented BroadBeam® waveguide technology delivers a consistent dispersion pattern up to 10 kHz for maximum coverage area per speaker (EASE™documented).
  • One 5.25 inch (133 mm) polypropylene woofer and one 1.0 inch (25 mm) convex titanium tweeter with FerroFluid cooling mounted to a proprietary castaluminum baffle and heat sink.
  • Weatherized components for indoor and outdoor applications.
  • Includes UL listed hanging hardware with cables and integrated SpeedClamp™ self-locking wire grip for fast, easy and secure installation. Also includes Euro-block connector and terminal weather boot.
  • Patented ZeroReflection™ enclosure technology for optimal sound reproduction and cabinet rigidity.
  • Easy-access, six-position selectable tap switch for 25-, 70.7- and 100-volt applica?tions with a transformer bypass position simplifies ordering and inventory tracking.
  • Plated steel grille with protective powdercoated finish for lasting durability.
  • Average senitivity 86.5 dB offers highoutput capabilities and reduced amplification costs.
  • UL 1480 (UEAY), CE and Milspec 810 approved.
  • High-quality black or white paint finish. Custom paint colors optional.
  • Optional accessory: AC-RS-SM5 surface mount bracket
System Type 5.25-inch, coaxial, open-ceiling, ported (33-watt transformer
for 25/70.7/100-voft or transformer bypass applications)
Impedance (nominal) 8 ohm
Sensitivity dB @ 2.38 V/lm 86.5 dB
Sensitivity dB ® 1 W/l m4 86.5 CB
Frequency Response (-3 dB)1 87 Hz-22 kHz
frequency (Response [-10 dB)1 61 Hz-22 kHz
Max. Program Power 150 watts
Max. Continuous Power RMS2 75 watts
Max. UL Power Rating3 50 watts
Ma... SPL dB & 1 m 105.5 dB
Coverage Angle (-6 dB & 2 kHz) 75°
Coverage Angle (-6 dB & 10 kHz) 105°
Coverage Angle (averaged 2-10 kHz) 95°
Directivity Factor (Q) 4.80 (Averaged 100 Hz -10 kHz); 12.30® 2 kHz
Directivity Index (DO 5.40 dB (Averaged 100 Hz -10 kHz): 10.9dB@2kHz
Tap Selector Six-posrtion rotary switch with transformer bypass
Transducer 1 x 133 mm (5.25 in.) polypropylene cone. butyl rubber surround
Low-frequency Driver 133 mm (5.25 in.) convex titanium tweeter with waveguide
High-Frequency DnVer 25 mm (1.00 in.)
Low-Frequency Voice Coil 25.4 mm (1.00 in.)
Crossover Frequency 3 kHz
Network Type: Low-Pass 12 dB per octave. 2nd order
Network Type: High-Pass 12 dB per octave. 2nd order
Enclosure Material Infection-molded ABS. glass fiber reinforced
Motor Board Cast aluminum
Grille Iridite-plated steel with powder-coat finish
Inputs Four-pin, 5.08 mm Euroblock for individual
or daisy chain connection
Colors Black or white
Height 298.2 mm (11.74 in.)
Diameter 245.9 mm (9.68 in.)
Weight 4.3 kg (9.5 lbs)
Shipping Weight 10 kg (22.0 bs) two per box
Packaging Two per box
Included Accessories Hanging hardware, Euroblock connector and terminal weather boot
Optional Accessories Surface mount bracket AC-RS-SM5
Regulatory UL UL 1480 (UEAY) and 2239 approved
RoHS Approved
