Q-8-WH 8-in COAX WEATHERPROOF Speaker/55Hz-17kHz/White by Soundsphere

SKU: Q-8-WH
Q-8-WH 8-in COAX WEATHERPROOF Speaker/55Hz-17kHz/White by Soundsphere

Q-8-WH 8-in COAX WEATHERPROOF Speaker/55Hz-17kHz/White by Soundsphere

  • $1050.00
OUT OF STOCK
  • Brand
    Soundsphere
  • SKU
    Q-8-WH
  • Weight
    30.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Discontinued
ASK AN EXPERT
Product Questions? Ask Our Experts!
Out of stock
The Model Q-8 is more robust than our compact Soundsphere loudspeakers models, offering greater sensitivity and power-handling capability.
  • Brand
    Soundsphere
  • SKU
    Q-8-WH
  • Weight
    30.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Discontinued
Questions? Ask our experts!

GET A QUOTE
  • $1050.00


The Model Q-8 is more robust than our compact Soundsphere loudspeaker models, offering greater sensitivity and power handling capability. Broad dispersion of all frequencies is achieved with an 8” coaxial driver and proprietary dispersion technologies, providing clear, full-range voice announcements and high-fidelity foreground and background music.

The Q-8 offers a hemispherical coverage pattern and is distinguished by its high sensitivity (93 dB 1 W/1 m) and high power handling capability (100 W RMS). It can evenly cover a large area with fewer speakers. The Q-8 comes fully assembled and ready to mount using our hanging kit or surface mounting bracket.

Features

  • Hemispherical coverage pattern
  • Accurate, full-range voice announcements
  • Enhanced high-fidelity music reproduction
  • High sensitivity
  • High power handling capability
  • Hanging or surface mount
  • Standard white (paintable) and custom colors available
System Type 8" (203 mm) coaxial
Impedance (nominal)1 8 ohms
Sensitivity dB@ 2.83 V/l m 93 dB
Sensitivity dB@l W/l m2 93 dB
Frequency Response (- 3 dB)3 200 Hz-17 kHz
Frequency Response (-10 dB)3 80 Hz - 20 kHz
Max. Continuous Peak Power4 200 W
Max. Continuous Power RMS5 100 W
Max. Power SPL@ 1 m6 113 dB
Coverage Angle (±6 dB @ 2 kHz) 135°
Coverage Angle (±6 dB @ 10 kHz)          190°
Coverage Angle (Avg. 500 Hz -10 kHz) 175°
Transformer Optional 100 W
Transducer - Low-Frequency Driver 8" (203 mm) treated pulp fiber
Transducer - High-Frequency Driver 3/4" (19 mm) mylar
Low-Frequency Voice Coil T (50.8 mm)
Crossover Frequency 1500 Hz
Network Type - High Pass First order
Enclosure & Reflector Material Fiberglass with gelcoat finish; rust-resistant hardware
Inputs Hard-wire leads
Colors White (paintable); custom colors available
Height 19" (483 mm)
Diameter Sphere: 16" (406 mm)
Reflector: 20" (508 mm)
Weight 22.5 lbs. (10.2 kg)
Shipping Weight 30 lbs. (13.6 kg)
Packaging One per box
Optional Accessories 100-Watt Line MatchingTransformer (TX100), Hanging Kit (HK), 24" Hanging Kit Extension (HKEXT), Mounting Bracket (MBM), Universal Beam Clamp with safety strap (BCM), Medium Screen (SM), Medium Screen with Weather Filter (SWFM)
Regulatory - CE Approved
RoHS Approved
