Micro-4K 4K UHD 4x 3G -SDI to SDI/HDMI Converter by Apantac

SKU: Micro-4K
  • Micro-4K 4K UHD 4x 3G -SDI to SDI/HDMI Converter by Apantac
  • Micro-4K 4K UHD 4x 3G -SDI to SDI/HDMI Converter by Apantac
Micro-4K 4K UHD 4x 3G -SDI to SDI/HDMI Converter by Apantac

Micro-4K 4K UHD 4x 3G -SDI to SDI/HDMI Converter by Apantac

  • $1045.00
Qty:
Make an Offer
  • Brand
    Apantac
  • SKU
    Micro-4K
  • Weight
    3.00 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
888.660.2962 Chat sales@avprosupply.com
In stock (50 items available)
4K (in the form of 4 x 3G SDI inputs) to 3G / HD / SD SDI converter. Can alternatively be used as a simple quad split. SDI output up to 1080p 50/60Hz. HDMI Output for monitoring. 8 GPI for presets.
  • Brand
    Apantac
  • SKU
    Micro-4K
  • Weight
    3.00 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
Product availability status
Questions? Ask our experts!

GET A QUOTE
  • $1045.00
Make an Offer


Model: Micro-4K - 4K (in the form of 4 x 3G SDI inputs) to 3G / HD / SD SDI converter. Can alternatively be used as a simple quad split. SDI output up to 1080p 50/60Hz. HDMI Output for monitoring. 8 GPI for presets.

Description:

Low Cost 4K to HD Down Converter

  • Supports 4K input
  • HDMI and SDI outputs up to 1080P
  • Supports up to 8 channels of embedded audio
  • Stereo Analog Audio Output
  • HDMI and Embedded SDI Audio Output

VIDEO INPUTS

4x 3G/HD/SD-SDI

VIDEO OUTPUTS

1 x HDMI, 1 SDI

TOTAL WINDOWS

1

HDMI

800x480 to 1920x1200 (1080p) 50/60 Hz

SERIAL DIGITAL

SMPTE 424M, 292M, 259M

SDI

Matching HDMI output resolution up to 3G

Equalization

120m at 2.97 Gbps, 140m at 1.48 Gbps, 400m at

270 Mbps with Belden 1694A

ON-SCREEN DISPLAY

Border, Label, Alarms and Audio Meters

Return Loss

> 15db up to 1.485 Gbps< > 10db up to 3G

GPI

8 for tally, Preset recall or ASCII

Embedded Audio

SMPTE-272M-A

IP

100 Base-Tx, TSL, AXP

ELECTRICAL

12 W, 90-250V 50/60Hz

EMI / RFI

Complies with FCC Part 15, Class A, CE, EU,

EMC, C-tick

POWER

5 DC 3A

SIZE

171 mm W x 120 mm D x 44.45 mm H

MOUNT

Magnetic
