MX-206 Mixer 6 Input Stereo Microphone/1U by Ashly

SKU: MX-206
  • MX-206 Mixer 6 Input Stereo Microphone/1U by Ashly
  • MX-206 Mixer 6 Input Stereo Microphone/1U by Ashly
MX-206 Mixer 6 Input Stereo Microphone/1U by Ashly

MX-206 Mixer 6 Input Stereo Microphone/1U by Ashly

  • $949.00
Market price: $1199.00, you save $250.00
  • 21% less
OUT OF STOCK
Make an Offer
  • Brand
    Ashly
  • SKU
    MX-206
  • Weight
    12.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
888.660.2962 Chat sales@avprosupply.com
Out of stock
Designed to be used by itself or as a supplementto larger mixing consoles, the MX-206 providessuperior audio performance in a single rack-space package. Equally at home in either fixed or portableinstallations, the MX-206 may be used anywhere where
  • Brand
    Ashly
  • SKU
    MX-206
  • Weight
    12.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Available
Product availability status
Questions? Ask our experts!

GET A QUOTE
  • $949.00
Market price: $1199.00, you save $250.00
  • 21% less
Make an Offer


Manual

Designed to be used by itself or as a supplement to larger mixing consoles, the MX-206 provides superior audio performance in a single rack-space package. Equally at home in either fixed or portable installations, the MX-206 may be used anywhere where additional microphone inputs are needed. Typical applications include live sound reinforcement, broadcast, recording, and film/video production. The MX-206 is a rack-mountable six input channel stereo microphone mixer offering up to 84dB of gain for distant mic placements or extremely low-level signals. Ultra low-noise, studio-grade discrete mic preamps are utilized. Each channel has a switchable 20dB pad, a 3-position mic gain switch input level and pan controls, and clip LED indicators, 48V phantom power may be switched in for use with condenser mics. A separate Stereo Line In volume control adjusts line level sources, such as a CD or MP3 player, connected to rear-panel RCA inputs or portable audio source connected to the 3.5mm jack located on the front panel. Since plenty of headroom has been designed into the MX-206, even the loudest signals can be handled without distortion. Output is monitored via two 5-segment, multi-colored LED meters, along with separate Peak Clip Indicators. The transformer-isolated XLR balanced mono output is capable of driving +24dBu into 600 Ohms, and separate stereo TRS 1/4" outputs may be used either balanced or unbalanced. A Stereo Line Out is available on RCA jacks. The MX-206 provides superior audio performance in a rugged and durable package. Backed by Ashly's exclusive Five Year Worry-Free Warranty, the MX-206 is designed to provide many years of trouble-free operation.

Features

  • Convenient, 3.5mm stereo line in jack on front panel for MP3 players and smartphones
  • High-gain mic preamps (60dB)
  • Transformer isolated +24dBm 600 Ohm balanced XLR-mono output
  • Stereo line in/out
  • Pan control on each channel
  • Stereo headphone jack with level control
  • 20dB input pad switch
  • +48V phantom power
  • Universal power supply
  • Safety/Compliance: cTUVus, CE, FCC, RoHS
Distortion, Hum and Noise
THD § +20dBu, 20Hz-20kHz, input switch at -40dB <0.05%
IMD (SMPTE) @ +20dBu, input switch at -40dB <0.02%
Equivalent Input Hum and Noise (input switch -60dB) <-128dBu
Residual Output Noise, TRS Outputs (All Levels @ min) <-100dBu
Residual Output Noise, XLR Outputs <-90dBu
Master Level at nominal, (All Ch. Level controls @ min) <-84dBu
Master Level and 1 Ch. Level at nominal <-80dBu
Voltage Gain (+2dB)
Mic Input to Master Output, 600 Ohm load 84dB
Aux In to Master Output 28dB
Frequency Response
20Hz—20kHz | +0/-0.5d8
Crosstalk
Between any inputs or outputs (20Hz—20kHz) <-60dB
Metering
VU Meters Two 5-segment LED meters, OVU = +4dBu
Peak Indicators Peak Clip indicator on each input channel and L/R outputs, illuminates 3dB below clipping
Weights, Dimensions & Power
Dimensions 19" W x 1.75" H x 9.4" D (483mm x44mm x 239mm)
Unit Weight 6.8lbs (3.9kg)
Shipping Weight 11lbs (5kg)
Power Requirements 100-240 VAC, 50-60Hz,30W
