KW-14T Wireless HD Extender (Transmitter) by Kramer

SKU: KW-14T
KW-14T Wireless HD Extender (Transmitter) by Kramer

KW-14T Wireless HD Extender (Transmitter) by Kramer

  • $648.00
Market price: $810.00, you save $162.00
  • 20% less
Qty:
Make an Offer
  • Brand
    Kramer
  • SKU
    KW-14T
  • Weight
    2.00 lbs
  • Warranty
    7 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
888.660.2962 Chat sales@avprosupply.com
In stock (50 items available)
The KW−14T is a high−definition, wireless, HDMI transmitter for indoor use. Up to four KW−14R receivers can receive from one KW−14T transmitter and up to three KW−14T transmitters can be paired with one KW−14R receiver. The KW−14T and KW−14R pair com
  • Brand
    Kramer
  • SKU
    KW-14T
  • Weight
    2.00 lbs
  • Warranty
    7 Years
  • Condition
    New
  • Status
    Available
Product availability status
Questions? Ask our experts!

GET A QUOTE
  • $648.00
Market price: $810.00, you save $162.00
  • 20% less
Make an Offer


Manual

The KW-14T is a high-definition, wireless, HDMI transmitter for indoor use. Up to four KW-14R receivers can receive from one KW-14T transmitter and up to three KW-14T transmitters can be paired with one KW-14R receiver. The KW-14T and KW-14R pair comes pre-associated.

Features

  • Max. Data Rate - 6.75Gbps (2.25Gbps per graphic channel), Deep Color up to 12-bit.
  • Secure Link - Uses AES-128 bit encryption.
  • Connection Capacity - Up to four receivers can receive from one transmitter simultaneously; up to three transmitters associated with one receiver at any given time.
  • Transmission Range - Up to 30m (100ft) including through walls and furniture.
  • Automatic Frequency Selection - Selects the most suitable frequencies to prevent RF interference.
  • Auto EDID Adjustment - To allow multi-screen support.
  • IR Remote Control - Enables the OSD menu to be displayed on the output display.
  • OSD (On Screen Display) - For simplified setup and configuration.
  • HDCP Compliant - HDCP sources are supported only when all connected displays support HDCP.
  • Zero Latency.
  • Automatic Sleep Mode - After three minutes when no input or link is detected.
  • CEC Support.
INPUT: 1 HDMI connector.
OUTPUT: 1 IR on a 3.5mm mini jack, internal antenna.
VIDEO RESOLUTION: Up to 1080p @60Hz; 8, 10, or 12-bit color depth and VESA up to 1920 x 1080 @60Hz.
FORMATS: RGB and YCbCr digital video.
MAXIMUM DATA RATE: 6.75Gbps (2.25Gbps per channel).
MAXIMUM PIXEL CLOCK: 148.5MHz.
AUDIO FORMATS: PCM, Dolby Digital 2/0, Dolby Digital 2/0 Surround, Dolby Digital 5.1, Dolby Digital Surround EX, DTS 2-channel, DTS Digital Surround 5.1, DTS 96/24.
AUDIO RATE: Digital audio from the HDMI input up to 6Mbps.
RF COMMUNICATION FREQUENCY: 5.19 to 5.795GHz (In Japan operation is limited to the lower bands 5.15 to 5.25GHz, in Israel operation is limited to 5.15 to 5.35GHz).
TRANSMISSION POWER: <18dBm conducted (KW-14T), <12dBm per channel conducted (KW-14R).
RECEIVING SENSITIVITY: –75dBm (KW-14T), –65dBm (KW-14R).
SYSTEM LATENCY: <1ms.
STANDARDS: HDMI with Deep Color, x.v.Color™, 3D, CEC; HDCP 2.0—works with sources that support HDCP repeater mode, DVI 1.0.
RF COMMUNICATION FREQUENCY: 5.19 to 5.795GHz (In Japan and Israel operation is limited to the lower bands; 5.15 to 5.25GHz).
UNOBSTRUCTED TRANSMISSION RANGE: 30m (100ft).
POWER CONSUMPTION: 5V DC, 1A.
OPERATING TEMPERATURE: 0° to +40°C (32° to 104°F).
STORAGE TEMPERATURE: –40° to +70°C (–40° to 158°F).
HUMIDITY: 10% to 90%, RHL non-condensing.
COOLING: Convection, vented.
ENCLOSURE TYPE: Plastic.
DIMENSIONS: 8.0cm x 10.2cm x 3.6cm (3.15" x 4.02" x 1.42") W, D, H.
WEIGHT: 0.1 kg (0.22lbs) approx.
SHIPPING WEIGHT: 0.45kg (1.0lbs) approx.
ENVIRONMENTAL REGULATORY COMPLIANCE: Complies with appropriate requirements of RoHS and WEEE.
VIBRATION: ISTA 1A in carton (International Safe Transit Association).
COMPLIANCE STANDARDS: CE, c-UL, UL.
EMMISSION STANDARDS: CE, C-tick, FCC Class B, ICES, VCCI, KC.
INCLUDED ACCESSORIES: Power supply 5V, 2 HDMI cables 0.9m (2.95ft) PN 2518-0101003, 1 IR emitter cable PN 3300-500135.
