INPUT: |
1 HDMI connector (KW-14T), internal antenna (KW-14R). |
OUTPUT: |
1 IR on a 3.5mm mini jack, internal antenna (KW-14T), 1 HDMI connector (KW-
14R). |
VIDEO RESOLUTION: |
Up to 1080p @60Hz; 8, 10, or 12-bit color depth and VESA up to 1920 x 1080
@60Hz. |
FORMATS: |
RGB and YCbCr digital video. |
MAXIMUM DATA RATE: |
6.75Gbps (2.25Gbps per channel). |
MAXIMUM PIXEL CLOCK: |
148.5MHz. |
AUDIO FORMATS: |
PCM, Dolby Digital 2/0, Dolby Digital 2/0 Surround, Dolby Digital 5.1,
Dolby Digital Surround EX, DTS 2-channel, DTS Digital Surround 5.1, DTS 96/24. |
AUDIO RATE: |
Digital audio from the HDMI input up to 6Mbps. |
IR COMMUNICATION: |
Unidirectional, 38 kHz. |
TRANSMISSION POWER: |
<18dBm conducted (KW-14T), <12dBm per channel conducted (KW-14R).
td>
|
RECEIVING SENSITIVITY: |
–75dBm (KW-14T), –65dBm (KW-14R). |
SYSTEM LATENCY: |
<1ms. |
STANDARDS: |
HDMI with Deep Color, x.v.Color™, 3D, CEC; HDCP 2.0—works with sources
that support HDCP repeater mode, DVI 1.0. |
RF COMMUNICATION FREQUENCY: |
5.19 to 5.795GHz (In Japan and Israel operation is limited to the lower
bands; 5.15 to 5.25GHz). |
UNOBSTRUCTED TRANSMISSION RANGE: |
30m (100ft) (KW-14T), 30m (100ft) (KW-14R). |
POWER CONSUMPTION: |
5V DC 1A (KW-14T), 5V DC 1.2A (KW-14R). |
OPERATING TEMPERATURE: |
0° to +40°C (32° to 104°F). |
STORAGE TEMPERATURE: |
–40° to +70°C (–40° to 158°F). |
HUMIDITY: |
10% to 90%, RHL non-condensing. |
COOLING: |
Convection, vented. |
ENCLOSURE TYPE: |
Plastic. |
DIMENSIONS: |
8.0cm x 10.2cm x 3.6cm (3.15" x 4.02" x 1.42") W, D, H (KW-14T), 9.5cm x
9.5cm x 3.4cm (3.74" x 3.747" x 1.34") W, D, H (KW-14R). |
ENVIRONMENTAL REGULATORY COMPLIANCE: |
Complies with appropriate requirements of RoHS and WEEE. |
VIBRATION: |
ISTA 1A in carton (International Safe Transit Association). |
COMPLIANCE STANDARDS: |
CE, c-UL, UL. |
EMMISSION STANDARDS: |
CE, C-tick, FCC Class B, ICES, VCCI, KC. |
INCLUDED ACCESSORIES: |
Power supply 5V, 2 HDMI cables 0.9m (2.95ft) PN 2518-0101003, 1 IR Emitter
cable PN 3300-500135. |
