KLR-2000 Power Amplifier 2 x (1000W 2)(600W 4)(350W 8) Ohms by Ashly

SKU: KLR-2000
KLR-2000 Power Amplifier 2 x (1000W 2)(600W 4)(350W 8) Ohms by Ashly

KLR-2000 Power Amplifier 2 x (1000W 2)(600W 4)(350W 8) Ohms by Ashly

  • $849.00
Market price: $1049.00, you save $200.00
  • 19% less
Qty:
  • Brand
    Ashly
  • SKU
    KLR-2000
  • Weight
    33.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
In stock (50 items available)
KLR-Series amplifiers are high-efficiency, lightweight high power amplifiers incorporating the latest amplifier technologies.
  • Brand
    Ashly
  • SKU
    KLR-2000
  • Weight
    33.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Available
Questions? Ask our experts!

GET A QUOTE
  • $849.00
Market price: $1049.00, you save $200.00
  • 19% less


This listing is for KLR-2000 Amplifier only. Use description below as a general reference.

KLR-Series amplifiers are high-efficiency, lightweight high power amplifiers incorporating the latest amplifier technologies.

The series provides a power range of 1000 to 2500 watts per channel at 2 ohms (20Hz- 20kHz, 1% THD). The KLR series is available in 2 channel versions at four power points. All models will drive 2, 4, or 8 ohm loads.

*The KLR 3200 can also be used as a two channel 70V distributed output amplifier providing up to 800W per channel. For 70V applications, Ashly recommends setting the amplifier’s HiPass filter switch to 50Hz

Features

  • Inputs are via 3-pin Euroblock, XLR, and ¼” TRS connectors.
  • Switch mode power supply provides high efficiency and low weight
  • Output connectors are four pin Speakon type.
  • Rear panel switches include: Gain and Operation Mode, Limiter, and HPF.
  • Forced air cooled (front panel intake, rear panel exhaust)
  • Front panel indicators for output level, clip/protect, and power on/off
  • Gain selectable switch for both channels
  • Removable dust filters on front panel
  • Rack ears for permanent installation in a standard 2RU 19”(rack mount width) enclosure
KLR Models 2000 3200 4000 5000
Max Output Power: Per Channel, 20Hz-20kHz, 196THD, Both Channels Driven |
2 Ohms 1.000W 1,600W 2.000W 2,500W
4 Ohms 600W 1,100W 1.400W 1,700W
8 Ohms 350W 650W 850W 1,000W
Bridge Mode, 20Hz-20kHz, 1%THD
4 Ohms 2.000W 3,200W 4.000W 5,000W |
Constant Voltage Options: Per Channel, 20Hz-20kHz, 1% THD
70V - 800W* - -
Line Current Draw: 120VAC 60Hz, All Channels Driven @ 4 Ohms
Idle 0.99A 0.92A 1.05A 1.14A
l/8th Power (Pink Noise) 9.7A 11.4A 14.0A 17.5A
1/3 Power (Sine Wave) 14.9A 16.6A 19.8A 24.7A
Thermal Dissipation: BTU/hr, All Channels Driven
Idle 164 136 171 215
l/8th Power (Pink Noise) 1876 2063 2489 3111
1/3 Power (Sine Wave) 2880 3001 3516 4395
Additional Specs
Signal-to-Noise (20Hz-20kHz, unweighted) >108dB >109dB >109dB >110dB
Input Gain Switch IV, 20dB, 26dB IV, 26dB, 32dB IV, 26dB, 32dB L4V, 26dB, 32dB
Output Circuitry Class AB 2-Step Class H 2-Step Class H 2-Step Class H



Specifications Note: OdBu = 0.775 VRMS
Frequency Response (1W @ 8 Ohms) 20Hz-20kHz (+0.3dB) 5Hz—70kHz (-3dB down point)
Damping Factor >380 (100Hz @ rated power (® 8 Ohms)
THD (20Hz—20kHz) lOdB below rated output @4 Ohms <0.05%
Input Impedance 12k Ohm, balanced
Max Input Level +21dBU
HPF 30Hz, 50Hz, Off (12dB/Oct)
Amplifier Protection Output Overcurrent, DC Output, Chassis Temperature, Mains Breaker (KLR-5000 uses internal Mains fuse)
Operating Temp/Humidity -10C to +40C/HumiditY: 0% to 90%
Front Panel
Airflow/Cooling Front-to-Rear, Variable Speed Fan
Front Panel Indicators Protection/Clip, Signal, Power
Attenuators Front Panel (each channel)
RearPonel
Input Connectors (each Ch) 3-pin Euroblodc, XLR, X* TRS Phone Jack
Output Connectors 4-pin SpeakON* type (each channel)
Power Cable Connector 3-prong NEMA 5-15,5-20 for KlK-5000
Weights, Dimensions & Power
Dimensions 19" W x 3.5" H x 16" D (482mm x 88mm x 407mm)
Unit Weight KLR-2000:26.2lbs (11.9kg) KLR-3200:26.4lbs (12kg) KLR-4000:26.6lbs (12kg) KLR-5000:28lbs (12.7kg)
Shipping Weight KLR-2000:31lbs (14kg) KLR-3200:33lbs (15kg) KLR-4000:33lbs (15kg) KLR-5000:35lbs (16kg)
Power Requirements 120VAC or 240VAC, +10% (factory set) 50-60Hz
