IPD4-CM52-BGM-WH 5.25 inch Ip4-Addressable Speaker Cat5/6 System/White by Soundtube

SKU: IPD4-CM52-BGM-WH
IPD4-CM52-BGM-WH 5.25 inch Ip4-Addressable Speaker Cat5/6 System/White by Soundtube

IPD4-CM52-BGM-WH 5.25 inch Ip4-Addressable Speaker Cat5/6 System/White by Soundtube

  • $563.20
Qty:
  • Brand
    Soundtube
  • SKU
    IPD4-CM52-BGM-WH
  • Weight
    10.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
In stock (50 items available)
Offering an economical option for expansion of audio coverage in a digital speaker system, this DanteTM-addressable coaxial in-ceiling speaker has output terminals for connection and power of up to three additional standard CM52-BGM speakers.
  • Brand
    Soundtube
  • SKU
    IPD4-CM52-BGM-WH
  • Weight
    10.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Available
Questions? Ask our experts!

GET A QUOTE
  • $563.20


Offering an economical option for expansion of audio coverage in a digital speaker system, this DanteTM-addressable coaxial in-ceiling speaker has output terminals for connection and power of up to three additional standard CM52-BGM speakers. The speaker incorporates one 5.25 inch (134 mm) polypropylene woofer with rubber surround and one 0.75 inch (19 mm) silk dome tweeter. BroadBeam Ring™ technology and a tuned port on the baffle provide smooth off-axis performance, mid-range clarity and bass response to 65 Hz (-10 dB). Low latency digital audio, power, and control are delivered to the speaker via standard category cable; connection is made on the other end to the STNet-Switch or other PoE / PoE+ switch. May also be powered via a 24V DC barrel connector for non-PoE installations. Configuration and zoning of the speaker are accomplished via software. When combined with standard speakers, the four-speaker cluster can be split and configured to handle two separate channels of audio. Mounting hardware is included and features SoundTube’s SpeedWing™ constant-tension fixed-wing mounting system, which accommodates material thicknesses ranging from 0.035 in (0.9 mm) to 2.38 in (60.4mm). UL 60065 and 2043 listed. Included accessories: Color-coded (orange) tile bridge, UL listed conduit clamp and paint shield.

Features:

  • IP-addressable, self powered (PoE) speaker with audio and power outputs for three standard CM52-BGM speakers.
  • DanteTM I/O for interconnectivity with Danteenabled audio systems.
  • One 5.25 inch (134 mm) polypropylene woofer with rubber surround and one 0.75 inch (19 mm) silk dome tweeter.
  • BroadBeam Ring™ technology for mid-range clarity and ultra wide off axis performance.
  • Fast connection of power, audio and control functions via one CAT5 or CAT6 cable.
  • 40 watts PoE provided by SoundTube STNet-Switch; also works with Standard PoE plus and PoE switches.
  • Input power is shared among speakers connected to IPD4 unit.
  • Two output channels available to additional speakers.
  • Provides report-back on any problems via SoundTube software.
  • Tuned port on baffle for added musicality and bass response down to 56 Hz (-10 dB).
  • Incorporates a painted steel grille for lasting durability.
  • SpeedWingTM clamping system is adaptable to material thicknesses ranging from 0.035 in. (0.9 mm) to 2.5 in. (63.5 mm).
  • UL 60065 and 2043 listed.
  • High-quality white painted finish. Custom colors available
  • Included accessories: Color-coded (green) tile bridge, UL listed conduit clamp, paint shield.
  • Optional accessories: Color-coded (green) pre-construction bracket (AC-CMEZ6/8- PCB).
Frequency Response (-3 dB) 90 Hz – 20 kHz
Frequency Response (-10 dB) 65 Hz – 22 kHz
Sensitivity 89 dB
Total Bi-Amp Power 40 W
Max SPL dB @ 1 M 93.0 dB
Tweeter 0.75 in. Silk
Connections RJ45 ethernet connector
Visible Height 8.6 mm (0.34 in)
Visible Diameter 298.5 mm (11.75 in)
Backcan Height 146.1 mm (5.75 in.)
Backcan Diameter 245.6 mm (9.67 in)
Weight 3.6 kg (8.0 lbs.)
Shipping Weight 4.1 kg (9.0 lbs.)
Certifications UL 60950 on STNet-Switch & Power Supply; UL 60065 on speakers; CE & CB on all
Optional Accessory Color-coded (orange) pre-construction
bracket (AC-CM6/8-PCB)
Colors White
