FiDO-4T 4-channel 3G-SDI to LC Optical Fiber Converter by AJA

SKU: FiDO-4T
FiDO-4T 4-channel 3G-SDI to LC Optical Fiber Converter by AJA

FiDO-4T 4-channel 3G-SDI to LC Optical Fiber Converter by AJA

  • $1869.00
Qty:
  • Brand
    AJA
  • SKU
    FiDO-4T
  • Weight
    2.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
In stock (50 items available)
FiDO Mini-Converters offer unmatched flexibility and cost efficiency for SDI-Fiber conversion, allowing for long cable runs up to 10km with electrical isolation - useful for eliminating ground loop problems
  • Brand
    AJA
  • SKU
    FiDO-4T
  • Weight
    2.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Available
Questions? Ask our experts!

GET A QUOTE
  • $1869.00


FiDO Mini-Converters offer unmatched flexibility and cost efficiency for SDI-Fiber conversion, allowing for long cable runs up to 10km with electrical isolation - useful for eliminating ground loop problems. FiDO converters use a compact, low-profile enclosure that works well in tight spaces around and behind equipment racks, trucks and on camera.

Features

  • 4 simplex or 2 duplex output connections (LC connector)
  • 4 independent channels of SDI, HD-SDI, or 3G SDI
  • 4K SDI over 4 fiber links
  • Uses 5-20VDC power (DWP-U-R1 universal power supply included)
  • 5-year warranty

Universal Power Supply

All AJA Mini-Converters ship with a universal power supply that includes international plug connections for use around the world.

Compact and Portable

AJA Mini-Converters are small enough to fit behind a monitor, in the back of a rack or directly on a camera rig. A locking power connector can't accidentally pull loose and an optional P-TAP power cable allows for battery power in remote locations.

AJA Quality - Guaranteed

All AJA Mini-Converters are covered by a 5 year warranty and AJA's advanced replacement policy. If a replacement is necessary, AJA will ship a new unit immediately without the need to send the original unit back first, ensuring you are up and running again as quickly as possible.

AJA Mini-Matrix

Information on the complete line of AJA Mini-Converters is now available as a mobile app on iOS. The Mini-Converter product line is extensive and this app helps you find the right converter for any situation, wherever you are.

Individual products have links back to the main AJA website for more details and you can email product information directly from the app. The free AJA Mini-Matrix app for iPad® and iPhone® is available now in the Apple iTunes®Store.

Formats

  • 3Gb, 1.5Gb, 270Mb, Auto Select

Video Inputs and Outputs

  • SDI (SMPTE 259/292/424), BNC
  • 1x Single mode optical fiber, LC connector (FiDO-R, FiDO-T)
  • 1x Single mode optical fiber, ST connector (FiDO-T-ST, FiDO-R-ST)
  • 1x Single mode optical fiber, SC connector (FiDO-T-SC, FiDO-R-SC)
  • 2x Single mode optical fiber, LC connectors (FiDO-2R, FiDO-2T, FiDO-TR)
  • 4x Single mode optical fiber, ST connectors (FiDO-4R-ST, FiDO-4T-ST)

Cable Equalization (BNC Inputs, 1694 coax)

  • 270mb, 400m
  • 1.5Gb, 200m
  • 3Gb, 140m

Input/Output Return Loss (BNC)

  • >15db, 270Mb - 3Gb

Optical Outputs

  • Wavelength: 13 10 nm
  • Output Power: -2dBm typical

Size

  • 4.6" x 1.71 " x.85" (117 x 43.5 x 21.6mm) - FiDO-T, FiDO-R, FiDO-T-ST, FiDO-R-ST, FiDO-T-SC, FiDO-R-SC, FiDO-2R, FiDO-2T, FiDO-TR
  • 4.6" x 4.10" x 0.92" (117 x 105 x 24mm) – FiDO-4T-ST, FiDO-4R-ST

Power

  • +5-20 VDC
  • 1.5 watts (FiDO-T, FiDO-R, FiDO-T-ST, FiDO-R-ST, FiDO-T-SC, FiDO-R-SC)
  • 2.5 watts (FiDO-2R, FiDO-2T, FiDO-TR)
  • 4.0 watts (FiDO-4R-ST, FiDO-4T-ST)
  • Requires Power Supply (AJA power supply model DWP-U-R1 included)
