FC-26 Ethernet to 2 Serial Port and 4 IR Port Controller by Kramer

SKU: FC-26
  • FC-26 Ethernet to 2 Serial Port and 4 IR Port Controller by Kramer
  • FC-26 Ethernet to 2 Serial Port and 4 IR Port Controller by Kramer
FC-26 Ethernet to 2 Serial Port and 4 IR Port Controller by Kramer

FC-26 Ethernet to 2 Serial Port and 4 IR Port Controller by Kramer

  • $340.00
Market price: $425.00, you save $85.00
  • 20% less
Qty:
Make an Offer
  • Brand
    Kramer
  • SKU
    FC-26
  • Weight
    3.00 lbs
  • Warranty
    7 years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
888.660.2962 Chat [email protected]
In stock (50 items available)
The FC-26 is a bidirectional RS-232 to Ethernet with IR control signal converter. It allows two RS-232 and four IR controllable devices to be controlled via an Ethernet or LAN connection.
  • Brand
    Kramer
  • SKU
    FC-26
  • Weight
    3.00 lbs
  • Warranty
    7 years
  • Condition
    New
  • Status
    Available
Product availability status
Questions? Ask our experts!

GET A QUOTE
  • $340.00
Market price: $425.00, you save $85.00
  • 20% less
Make an Offer


Manual

The FC-26 is a bidirectional RS-232 to Ethernet with IR control signal converter. It allows two RS-232 and four IR controllable devices to be controlled via an Ethernet or LAN connection.

Features

  • Ports - 2 RS-232, 1 Ethernet, 4 IR emitters, 1 IR learning.
  • Simultaneous Communication - With up to 40 PC clients.
  • USB Port - For firmware upgrades.
  • Size - Compact TOOLS - 3 units can be rack mounted side-by-side in a 1U rack space with the optional RK-3T rack adapter.
OUTPUTS: 4 IR on 3.5mm mini jacks.
PORTS: 2 RS-232 serial on 3-pin terminal blocks, 1 Ethernet on an RJ-45 connector, 1 USB on a mini USB connector for programming, 1 built-in IR sensor (for learning).
SUPPORTED SERIAL PORT BAUD RATES: 1200, 2400, 4800, 9600, 19200, 38400, 57600, 15200bps.
RS-232 COMMUNICATION: Transparent up to 115200bps.
IR EMITTER CABLE RANGE: 80m (260ft).
SUPPORTED IR INPUT FREQUENCIES: 20kHz to 60kHz.
SUPPORTED IR OUTPUT FREQUENCIES: 20kHz to 1.2MHz.
MAXIMUM DATA HANDLING OF DEVICE: Up to 150kbps summed on all ports.
SUPPORTED WEB BROWSERS: Windows 7 and higher: Internet Explorer (32/64 bit) version 11, Firefox version 30, Chrome version 35. MAC: Chrome version 35, Firefox version 27, Safari version 7. Android OS: Chrome version 35. iOS: Chrome version 35, Safari version 7.
POWER CONSUMPTION: 5V DC, 230mA.
OPERATING TEMPERATURE: 0° to +40°C (32° to 104°F).
STORAGE TEMPERATURE: –40° to +70°C (–40° to 158°F).
HUMIDITY: 10% to 90%, RHL non-condensing.
COOLING: Convection.
ENCLOSURE TYPE: Aluminium.
RACK MOUNT: With optional rack adapter.
DIMENSIONS: 12cm x 7.5cm x 2.44cm (4.72” x 2.95” x 0.96”) W, D, H.
PRODUCT WEIGHT: 0.182kg (0.4lbs) approx.
VIBRATION: ISTA 1A in carton (International Safe Transit Association).
SAFETY REGULATORY COMPLIANCE: CE.
ENVIRONMENTAL REGULATORY COMPLIANCE: Complies with appropriate requirements of RoHs and WEEE.
INCLUDED ACCESSORIES: Power adapter, IR Cable C-A35M/IRE-10.
OPTIONS: 19“ Rack adapter RK-3T, IR cables: C-A35M/2IRE-10, C-A35M/IRR-3, C-AS35M/AS35F-50, C-A35M/IRE-10; bulk cable for serial control BC-1T-300M.
