DS-RC2ST 2 Channel Remote Control for STICK-ONs/stainless steel by RDL

SKU: DS-RC2ST
DS-RC2ST 2 Channel Remote Control for STICK-ONs/stainless steel by RDL

DS-RC2ST 2 Channel Remote Control for STICK-ONs/stainless steel by RDL

  • $146.75
Market price: $163.05, you save $16.30
  • 10% less
Qty:
  • Brand
    RDL
  • SKU
    DS-RC2ST
  • Weight
    1.00 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
In stock (50 items available)
The front panel of the DS-RC2ST features two pushbuttons with two associated LEDs. Upon initial power-up, source 1 is selected. Touching the other button de-selects source 1 and immediately selects source 2.
  • Brand
    RDL
  • SKU
    DS-RC2ST
  • Weight
    1.00 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
Questions? Ask our experts!

GET A QUOTE
  • $146.75
Market price: $163.05, you save $16.30
  • 10% less


The front panel of the DS-RC2ST features two pushbuttons with two associated LEDs. Upon initial power-up, source 1 is selected. Touching the other button de-selects source 1 and immediately selects source 2. An LED adjacent to each button shows which source is selected.

In a typical installation, the DS-RC2ST may be used to select between two audio or video sources, or to route audio to two destinations. To select between two audio sources, the DS-RC2ST is connected to an RDL ST-SSR1 Solid-State Audio Switch. For video switching, an RDL TX-MVX may be used. For audio routing, an RDL ST-RX2 is used. In each of the above examples, only one output terminal is needed for triggering. Therefore a single shielded pair (or 3-conductor cable) is required for remote connection. For more complex switching networks, both outputs may be used.

In installations where ULTRASTYLE™ wall controls are preferred, use the RUC-4 Universal Remote Control.

Features

  • Remote Selection of 2 Audio Sources, Destinations or Functions
  • Single-Button Selection for Each Source
  • Open-collector Switching of 1 of 2 Module Functions
  • 3-wire or 4-wire Remote Wiring
  • Professional Aesthetic Appearance
  • Companion to other RDL® Remote Controls
Selectors (2): Momentary pushbuttons, (1 for each channel)
Indicators (2): Red LEDs, (indicates channel selected)
Connections: Detachable terminal block; Power input; open-collector outputs (25 mA current limited)
Ambient Operating Environment: -10° C to 55° C
Power Requirement: GROUND-REFERENCED, 24 Vdc :c: 30 -A
Mounting: Mounts in standard US electrical box, RDL WB- or SMB- series boxes; cover plate available separately
Package Type: Cardboard Box
Package Dimensions: 3.625 x 4.625 x 2.125 in.
Shipping Weight: 0.37 IbS.
WEEE weight: 0.215 lbs.
Tariff code: 8517.62.0050
