DB-RT2 Remote Control Selector/Black by RDL

SKU: DB-RT2
DB-RT2 Remote Control Selector/Black by RDL

DB-RT2 Remote Control Selector/Black by RDL

  • $158.48
Market price: $176.09, you save $17.61
  • 10% less
OUT OF STOCK
  • Brand
    RDL
  • SKU
    DB-RT2
  • Weight
    1.00 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
Out of stock
The front panel of the DB-RT2 features two pushbuttons with two associated LEDs. Upon initial power-up, the OFF mode is selected. Touching the other button de-selects OFF and immediately selects ON. An LED adjacent to each button shows which mode is
  • Brand
    RDL
  • SKU
    DB-RT2
  • Weight
    1.00 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
Questions? Ask our experts!

GET A QUOTE
  • $158.48
Market price: $176.09, you save $17.61
  • 10% less


The front panel of the DB-RT2 features two pushbuttons with two associated LEDs. Upon initial power-up, the OFF mode is selected. Touching the other button de-selects OFF and immediately selects ON. An LED adjacent to each button shows which mode is selected.

In a typical installation, the DB-RT2 may be used to turn an audio or video source on or off. To turn on an audio source, the DB-RT2 may be connected to an RDL ST-SSR1 or ST-RX2 Solid-State Audio Switch. For video switching, an RDL TX-MVX may be used. In each of the above examples, only one output terminal is needed for triggering, therefore a single shielded pair (3-conductor cable) is required for remote connection. For more complex switching networks, both outputs (ON and OFF) may be used. In an audio or video control installation, the DB-RT2 may be mounted adjacent to an RDL remote volume control, such as the RLC2, RLC3 or RLC10K.

In installations where ULTRASTYLE™ wall controls are preferred, use the RUC-4 Universal Remote.

Features

  • Remote Selection of ON or OFF
  • Single-Button Selection for Each Function
  • Open-collector Switching
  • 3-wire or 4-wire Remote Wiring
  • Professional Aesthetic Appearance
  • Companion to other RDL® Remote Controls
  • LED Indication
Selectors (2): Momentary pushbuttons, (1 for ON, 1 for OFF)
Indicators (2): Green/Red LEDs, (indicates status ON or OFF respectively)
Connections: Detachable terminal block; Power input; Separate open-collector outputs for ON and OFF (25 mA max.)
Ambient Operating Environment: 0° C to 55° C
Power Requirement: GROUND-REFERENCED, 24 Vdc :c: 30 mA
Mounting: Mounts in standard US electrical box, RDL WB- or SMB- series boxes; cover plate available separately
Package Type: Cardboard Box
Package Dimensions: 3.625 x 4.625 x 2.125 in.
Shipping Weight: 0.365 ins.
WEEE weight: 0.22 ins.
Tariff code: 8517.62.0050
