CS1308 8-Port PS/2-USB VGA KVM Switch by Aten

SKU: CS1308
  • CS1308 8-Port PS/2-USB VGA KVM Switch by Aten
  • CS1308 8-Port PS/2-USB VGA KVM Switch by Aten
  • CS1308 8-Port PS/2-USB VGA KVM Switch by Aten
CS1308 8-Port PS/2-USB VGA KVM Switch by Aten

CS1308 8-Port PS/2-USB VGA KVM Switch by Aten

  • $317.00
Qty:
Make an Offer
  • Brand
    Aten
  • SKU
    CS1308
  • Weight
    5.00 lbs
  • Warranty
    1 Year
  • Condition
    New
  • Status
    Backordered
ASK AN EXPERT
Product Questions? Ask Our Experts!
888.660.2962 Chat sales@avprosupply.com
In stock (50 items available)
The CS1308 KVM switch allows access and control up to 64 computers from a single console (keyboard, mouse, and monitor)
  • Brand
    Aten
  • SKU
    CS1308
  • Weight
    5.00 lbs
  • Warranty
    1 Year
  • Condition
    New
  • Status
    Backordered
Product availability status
Questions? Ask our experts!

GET A QUOTE
  • $317.00
Make an Offer


Manual

The CS1308 KVM switch allows access and control up to 64 computers from a single console (keyboard, mouse, and monitor). As many as 8 additional switches can be cascaded bringing the total number of connected computers to 64 computers that can be controlled from a single keyboard-monitor-mouse console. The switch supports both USB and PS/2 connections for the console and computers.

  • One USB-PS/2 console controls 8 computers
  • Cascade up to 2 levels - control up to 64 computers
  • Dual Interface - supports computers with PS/2 or USB keyboards and mice
  • Multiplatform support - Windows 2000/XP/Vista, Linux, Mac, and Sun
  • Video DynaSync™ - Exclusive ATEN technology eliminates boot-up display problems and optimizes resolution when switching between ports
  • Supports USB keyboards for PC, Mac and Sun
  • Auto PS/2 and USB interface detection
  • USB or PS/2 keyboard and mouse emulation - computers boot even when the console focus is elsewhere
  • Superior video quality - up to 2048 x 1536; DDC2B
  • Computer selection via front panel pushbuttons, hotkeys and multilingual on-screen display (OSD) menu
  • Two level password security - only authorized users view and control computers; up to four users and an administrator with a separate profile for each
  • Auto Scan feature for monitoring user-selected computers
  • Hot pluggable - add or remove computers without having to power down the switch
  • Buzzer on/off via hotkey and OSD
  • Firmware upgradeable
  • No software installation required
  • Designed for desktop or rack mount (19" system rack, 1U)
Computer Connections
Direct 8
Maximum 64 (via Cascade)
Port Selection OSD, Hotkey, Pushbutton
Connectors
Console Ports 1 x SPHD-18 Male (Yellow)
KVM Ports 8 x SPHD-15 Female (Yellow)
Firmware Upgrade 1 x RJ-11 Female (Black)
Power 1 x DC Jack
Switches
Ports 8 x Pushbutton
Firmware Upgrade 1 x Slide
LEDs
Online 8 (Orange)
Selected 8 (Green)
Power 1 (Dark Green)
Emulation
Keyboard / Mouse PS/2, USB
Video 2048 x 1536; DDC2B
Scan Interval 1 – 255 Seconds (Default: 5 secs)
Power Consumption DC 5.3 V; 5 W
Environmental
Operating Temperature 0-50˚C
Storage Temperature -20-60˚C
Humidity 0-80% RH, Non-condensing
Physical Properties
Housing Metal
Weight 1.89 kg ( 4.16 lb )
Dimensions (L x W x H) 43.72 x 16.13 x 4.40 cm (17.21 x 6.35 x 1.73 in.)
