CM82-EZs-II-WH 8in COAXIAL IN-CEILING SHALLOW BACKCAN SPEAKER/White by Soundtube

SKU: CM82-EZs-II-WH
CM82-EZs-II-WH 8in COAXIAL IN-CEILING SHALLOW BACKCAN SPEAKER/White by Soundtube

CM82-EZs-II-WH 8in COAXIAL IN-CEILING SHALLOW BACKCAN SPEAKER/White by Soundtube

  • $183.50
Qty:
  • Brand
    Soundtube
  • SKU
    CM82-EZs-II-WH
  • Weight
    10.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
In stock (50 items available)
The CM82-EZs-II is an 8-inch, coaxial, two-way, blind-mount, in-ceiling speaker which delivers true high efficiency and performance across the operating band?width.
  • Brand
    Soundtube
  • SKU
    CM82-EZs-II-WH
  • Weight
    10.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Available
Questions? Ask our experts!

GET A QUOTE
  • $183.50


The CM82-EZs-II is an 8-inch, coaxial, two-way, blind-mount, in-ceiling speaker which delivers true high efficiency and performance across the operating bandwidth. By incorporating an 8-inch polypropylene driver with a butyl rubber surround in a sealed drawn steel backcan, this speaker delivers maximum frequency response (82 Hz – 22 kHz, - 10 dB) in an integrated enclosure design.

Mounting hardware is included and features a constant-tension fixed-wing mounting system with a 21-gauge “full-metal” steel tile bridge ensuring rapid and secure installation in any sheetrock or drop-tile application. For easy ordering, stocking and installation, this series includes a color-coded (green) tile bridge and optional pre-construction bracket, six-position tap switch for 25-, 70.7- and 100-volt applications with transformer bypass position.

Features

  • Engineered for applications with limited plenum space incorporating a SoundTube-specific shallow backcan with an installed depth of 3.5 inches.
  • One 8 inch (203 mm) polypropylene woofer with butyl rubber surround and one 1.0 inch (25.4 mm) silk dome tweeter.
  • Easy-access six-position tap switch for 25/70.7/100-volt and 16 ohm transformer bypass settings allows for easy ordering, stocking and installation.
  • Reduced amplification costs and maximum efficiency of 88.0 dB sensitivity, 16 ohm impedance and a sealed enclosure.
  • Superior voice intelligibility with an average coverage angle of 105° (2–10 kHz, independently verified).
  • Cost-effective 16 ohm settings allows for the use of multiples of two, four, or six speakers in a system using a standard amplifier without a transformer.
  • Incorporates a painted steel grille with rust inhibitor for lasting durability.
  • Adaptable to ceiling thicknesses ranging from 0.04 inch (0.9 mm) to 1.60 inch (40.6 mm).
  • UL 1480 (UEAY) and 2043, cUL, CE (EMC Directive 89/366/EEC, EN55020, EN55013) approved.
  • High-quality black or white painted finish. Custom colors available.
  • Included accessories: tile bridge, UL-listed 0.5-inch conduit clamp, paint shield and two wire nuts.
  • Optional accessories: color-coded (green) pre-construction bracket (AC-CMEZ6/8- PCB) and junction box (AC-CM-EZ-JBOX).
System Type 8-inch coaxial, in-ceiling, sealed (64-watt transformer for 25/70.7/1OOvott or transformer bypass)
Impedance (nominal)1 16 ohm
Sensitivity dB @ 2.83 V/l m 85 dB
Sensitivity dB @ 1 W/l m2 88 dB
Frequency Response (- 3 dB)3 109 Hz-18 kHz
Frequency Response (-10 dB)3 82 Hz-22 kHz
Max. Program Power4 128W
Max. Continuous Power RMS5 64 W
Max. Power SPL @ 1 m 6 106.0 dB
Coverage Angle (-6 dB @ 2 kHz) 105°
Coverage Angle (-6 dB @ 10 kHz) 35°
Coverage Angle (averaged 2-10 kHz) 105°
Directivity Factor (Q) 5.2 (averaged 100 Hz -10 kHz); 6.8 (2 kHz)
Directivity Index (Dl) 5.5 dB (averaged 100 Hz -10 kHz); 8.3 dB (2 kHz)
Tap Selector Six-position rotary switch with transformer bypass position
Transducer - Low-Frequency Driver 203 mm (8 in.) Polypropylene cone, butyl rubber surround
Transducer - High-Frequency Driver 25.4 mm (1.0 in.) Silk dome tweeter
Low-Frequency Voice Coil 25.4 mm (1.00 in.)
Crossover Frequency 3.0 kHz
Network Type: Low Pass 6 dB per octave, 1st order
Network Type: High Pass 6 dB per octave, 1st order
Enclosure Material Drawn steel backcan with ABS baffle
Grille Painted steel
Inputs 4 position ceramic terminal strip
Colors Black or white
Backcan Diameter 245.6 mm (9.67 in.)
Backcan Height 95.3 mm (3.75 ii.)
Visible Diameter 298.5 mm (11.75 in.)
Visible Height 8.6 mm (0.34 in.)
Mounting Hole Diameter 266.7 mm (10.50 rO
Min - Max Ceiling Thickness 0.9 mm (0.04 in.) -40.6 mm (1.60 in.)
Weight 3.2 kg (7.0 lbs.)
Shipping Weight 4.1kg (9.0 lbs.)
Packaging One per box
Included accessories Tile bridge, UL-listed flex conduit clamp, paint shield, cutout template, two wire nuts
Optional accessories Preconstniction bracket (ACCMEZe/STCB); junction box (ACCM-EZ-JBOX)
Regulatory - UL UL 1480 (UEAY) and 2043 approved
Regulatory - CE Approved
RoHS Approved
