| System Type |
8-inch coaxial, in-ceiling, sealed (64-watt transformer for 25/70.7/100-vott or transformer bypass) |
| Impedance (nominal)1 |
16 ohm |
| Sensitivity dB @ 2.83 V/l m |
86 dB |
| Sensitivity dB @ 1 W/l m2 |
89 dB |
| Frequency Response (- 3 dB)3 |
92 Hz-18 kHz |
| Frequency Response (-10 dB)3 |
65 Hz-22 kHz |
| Max. Program Power4 |
128W |
| Max. Continuous Power RMS5 |
64 W |
| Max. Power SPL @ 1 m 6 |
107 dB |
| Coverage Angle (-6 dB @ 2 kHz) |
105° |
| Coverage Angle (-6 dB @ 10 kHz) |
40° |
| Coverage Angle (averaged 2-10 kHz) |
95° |
| Directivity Factor (Q) |
5.4 (averaged 100 Hz -10 kHz); 7.2 (2 kHz) |
| Directivity Index (Dl) |
5.5 dB (averaged 100 Hz -10 kHz); 8.6 dB (2 kHz) |
| Tap Selector |
Six-position rotary switch with transformer bypass position |
| Transducer - Low-Frequency Driver |
203 mm (8 in.) polypropylene cone, butyl rubber surround |
| Transducer - High Frequency Driver |
2b.A mm (1.0 in.) silk dome: tweeter |
| Low-Frequency Voice Coil |
25.4 mm (1.00 in.) |
| Crossover Frequency |
3.0 kHz |
| Network Type: Low Pass |
6 dB per octave, 1st order |
| Network Type: High Pass |
6 dB per octave, 1st order |
| Enclosure Material |
Drawn steel backcan with ABS baffle |
| Grille |
Steel with painted finish |
| Inputs |
4 position ceramic terminal strip |
| Colors |
Black or white |
| Backcan Diameter |
245.6 mm (9.67 in.) |
| Backcan Height |
146.1mm (5.75 ii.) |
| Visible Diameter |
298.5 mm (11.75 in.) |
| Visible Height |
8.6 mm (0.34 in.) |
| Mounting Hole Diameter |
266.7 mm (10.50 rO |
| Min - Max Ceiling Thickness |
0.9 mm (0.04 in.) - 40.6 mm (1.60 in.) |
| Weight |
4.1kg (9.0 lbs.) |
| Shipping Weight |
4.5 kg (10.0 lbs.) |
| Included accessories |
Tile bridge, UL-listed flex conduit clamp, paint shield, cutout template, two wire nuts |
| Optional accessories |
Preconstructjon bracket (ACCMEZ6/STCB), junction box (ACCM-EZ-JBOX) |
| Packaging |
One per box |
| Regulatory - UL |
UL 1480 (UEAY) and 2043 approved |
| Regulatory - CE |
Approved |
| RoHS |
Approved |
