CM31-EZ-WH 3in PREMIUM F-RANGE IN-CEILING SPEAKERS/190Hz-12kHz/White by Soundtube

SKU: CM31-EZ-WH
CM31-EZ-WH 3in PREMIUM F-RANGE IN-CEILING SPEAKERS/190Hz-12kHz/White by Soundtube

CM31-EZ-WH 3in PREMIUM F-RANGE IN-CEILING SPEAKERS/190Hz-12kHz/White by Soundtube

  • $130.00
Qty:
Make an Offer
  • Brand
    Soundtube
  • SKU
    CM31-EZ-WH
  • Weight
    4.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
888.660.2962 Chat sales@avprosupply.com
In stock (50 items available)
The CM31-EZ is a premium full-range 3-inch in-ceiling speaker for applications requiring 8 ohm or distributed audio solutions. The CM31-EZ incorporates low prole grille with a total visible footprint of 6.3 inch diameter and an integrated backcan
  • Brand
    Soundtube
  • SKU
    CM31-EZ-WH
  • Weight
    4.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Available
Product availability status
Questions? Ask our experts!

GET A QUOTE
  • $130.00
Make an Offer


The CM31-EZ is a premium full-range 3-inch in-ceiling speaker for applications requiring 8 ohm or distributed audio solutions. The CM31-EZ incorporates low prole grille with a total visible footprint of 6.3 inch diameter and an integrated backcan and driver design for ultra compact in-ceiling installations. The in-ceiling speaker includes a six-position tap switch with a transformer bypass position. A tile bridge and mounting hardware are included and feature a fast and secure constant tension SpeedWing™ mounting system. The CM31-EZ incorporates weatherized components for indoor/outdoor applications.

Features

  • One 3 inch (76.2 mm) full-range high-extrusion, high-delity polypropylene driver with butyl rubber surround.
  • Weatherized components for indoor/out-door applications.
  • Shallow 3.5 inch (88.9 mm) deep all-steel backcan with integrated driver and bafe conguration.
  • Ultra-compact design with a total visible footprint of less than 6.3 inch (160.6 mm) diameter.
  • Rapid installation, blind-mount, xed-wing mounting mechanism with constant tension design afxing to wall thicknesses ranging from 0.1 in. (2.5 mm) to 1.5 in. (38.1 mm).
  • Corrosion-resistant, powder-coated aluminum grille with snap t attachment.
  • UL 1480 (UEAY) and 2043 approved.
  • High quality black or white paint nish.
  • Included accessories: Tile bridge.
  • Optional accessories: Pre-construction bracket (AC-CM3-PCB) and 10-inch powered subwoofer (SM1001p)
System Type 3 inch fulrange, inceiling (10 watt transformer
for 25/70.7/100-volt or transformer bypass position)
Impedance (nominal)1 8 ohm
Sensitivity dB @ 2.83 V/l m 85.0 d8
Sensitivity dB @ 1 W/l m 2 85.0 dB
Frequency Response (- 3 dB)3 218 Hz-14 kHz
Frequency Response (-10 dB)3 135 Hz-22 kHz
Max. Program Power ; 40 W
Max. Continuous Power RMS b 20 W
Max. Power SPL @ 1 m 6 98.0 dB
Coverage Angle (-6 dB @ 2 kHz) 175°
Coverage Angle (-6 dB @ 10 kHz) 45°
Coverage Angle (averaged from 2 to 10 kHz) 120°
Directivity Factor (QJ 4.5 (averaged 100Hz - 10kHz). 3.5 (2kHz)
Directivity Index (Dl) dB 5.3 (averaged 100Hz - 10kHz), 5.2 (2kHz)
Tap Selector (transformer accessory only) Six-position rotary switch or transformer bypass position
Transducer - Full-Range Driver 76.1 mm (3.0 in.) Polypropylene driver with butyl rubber surround
Low Frequency Voice Coil 19.0 mm (0.75 in.)
Enclosure Material ABS baffle, steel backcan
Grille CorrosiorMesistant, powder-coated aluminum
Inputs Hardwire lead
Colors Black or white
Backcan Diameter 139.7 mm (5.5 in.)
Backcan Height 88.9 m:n (3.5 in.)
Visible Height 15.2 mm (0.6 in.)
Visible Diameter 160.6 mm (6.3 in.)
Weight 1.4 kg (3. lbs.)
Shipping Weight 1.8 kg (4.0 bs.)
Packaging One per box
Included Accessories Tile Bridge, condurt connector, paint mask and wire nuts
Optional Accessories Pre-construcbon bracket (AC-CM3-PCB), 10 inch powered subwoofer(SM1001p)
Regulatory - UL UL 1480 (UEAY) and 2043 approved
Regulatory - CE Approved
RoHS Approved
