CM1001d-T-WH 10in IN-CEILING SUBWOOFER/55 Hz - 118 Hz/White by Soundtube

SKU: CM1001d-T-WH
CM1001d-T-WH 10in IN-CEILING SUBWOOFER/55 Hz - 118 Hz/White by Soundtube

CM1001d-T-WH 10in IN-CEILING SUBWOOFER/55 Hz - 118 Hz/White by Soundtube

  • $680.00
Qty:
Make an Offer
  • Brand
    Soundtube
  • SKU
    CM1001d-T-WH
  • Weight
    32.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
888.660.2962 Chat sales@avprosupply.com
In stock (50 items available)
The CM1001d-T is a 10-inch, blind-mount, in-ceiling subwoofer tuned for maximum output and performance across the operating bandwidth.
  • Brand
    Soundtube
  • SKU
    CM1001d-T-WH
  • Weight
    32.00 lbs
  • Warranty
    5 Years
  • Condition
    New
  • Status
    Available
Product availability status
Questions? Ask our experts!

GET A QUOTE
  • $680.00
Make an Offer


The CM1001d-T is a 10-inch, blind-mount, in-ceiling subwoofer tuned for maximum output and performance across the operating bandwidth. By incorporating a 10-inch polypropylene woofer and a butyl rubber surround in a tuned and ported enclosure, this speaker delivers maximum low-frequency response (41 Hz – 224 Hz, - 10 dB) and high SPL (111 dB). For added low-end punch, SoundTube has incorporated an oversized enclosure and tuned, flared port.

Mounting hardware is included and features a constant-tension fixed-wing mounting system with a 21-gauge “full-metal” steel tile bridge, ensuring rapid and secure installa?tion in any sheetrock or drop-tile application. Restraint cable included for easier installation. For easy ordering, stocking and installation, the CM1001d-T includes a color-coded (purple) tile bridge and ships with a five-position tap switch for 25-, 70.7- and 100-volt applications with transformer bypass position.

Features

  • One 10 inch (254 mm) polypropylene cone with a butyl rubber surround on a reinforced ABS baffle.
  • High output (111 dB SPL) and maximum efficiency with an accentuated 70 Hz peak to maximize listener’s low-frequency experience.
  • Extra-large SoundTube-specific 12.9 liter steel DeepCan (12.46-inch depth) for quality bass response.
  • Rapid-installation, blind-mount, fixed-wing mounting mechanism with constanttension design affixing to ceiling thicknesses ranging from 0.25 inch (6.4 mm) to 1.91 inch (48.5 mm).
  • Easy-access five-position tap switch for 25/70.7/100-volt and transformer bypass position.
  • Steel grille with protective powder-coated finish for lasting durability plus a tool-free strap for easy installation.
  • Baffle-mounted, flared and tuned port for maximum efficiency and frequency response.
  • UL 1480 (UEAY) and 2043, CE (EMC Directive 89/366/EEC, EN55020, EN55013) approved.
  • High-quality black or white painted finish. Custom colors available.
  • Included accessories: Color-coded (purple) tile bridge, grille, UL-rated cover plate, four?pin Euroblock, paint shield and restraint cable.
  • Optional accessories: Color-coded (purple) pre-construction bracket (AC-CM8-PCB), junction box (AC-CMi-JBOX).
System Type l0-inch subwoofer, irvceiling, ported (150-watt transformer
for 25/70.7/100-volt or transformer bypass)
Impedance (nominal)1 4 ohm
Sensitivity dB @ 2.83 V/l m 92.0 dB
Sensitivity dB @ 1 W/l m 2 89.0 dB
Frequency Response (- 3 dB)3 55 Hz-118 Hz
Frequency Response (-10 dB)3 41 Hz-224 Hz
Max. Program Power4 300 w
Max. Continuous Power RMS 4 150w
Max. Power SPL @ 1 m 0 111.0 dB
Low-Frequency Driver 254 mm (10 in.) Polypropylene cone, butyl rubber surround
Low-Frequency Voice Coil 35.0 mm (1.38 in.)
Crossover Frequency 100 Hz
Low-Pass Filter 6 dB per octave, 1st order
Enclosure Material Drawn steel backcan with ABS baffle
Motor Board N/A
Grille Powder coated steel with integrated ABS baffle
Inputs Four-pin, 5.08 mm Euroblock for individual
or daisy chain connection
Colors Black or white
Backcan Height 316.5 mm (12.46 in)
Visible Diameter 374.9 mm (14.76 in.)
Visible Height 27.4 mm (1.08 in.)
Mounting Hole Diameter 323.9 mm (12.75 in.)
Min. Ceiling Thickness 6.4 mm (0.25 in.)
Max. Ceiling thickness 48.5 mm (1.91 in)
Weight 12.3 kg (27.0 lb.)
Shipping Weight 14.5 kg (32.0 lb.)
Included accessories Tile bridge, Euroblock connector, paint mask, restraint cable
Optional accessories Pre-construction bracket (AC-CM8PCB),
junction box (AC-CM-JB0X)
Packaging One per box
Regulatory-CE Approved
Regulatory - UL UL 1480 (UEAY) and 2043 Approved
RoHS Approved
