ANI-4K-VW 1x4 HDMI 4K Video Wall Splitter/Cascadable by A-NeuVideo

SKU: ANI-4K-VW
ANI-4K-VW 1x4 HDMI 4K Video Wall Splitter/Cascadable by A-NeuVideo

ANI-4K-VW 1x4 HDMI 4K Video Wall Splitter/Cascadable by A-NeuVideo

  • $1123.20
Market price: $1295.00, you save $171.80
  • 13% less
Qty:
  • Brand
    A-NeuVideo
  • SKU
    ANI-4K-VW
  • Weight
    10.00 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
ASK AN EXPERT
Product Questions? Ask Our Experts!
In stock (50 items available)
The ANI-4K-VW 1x4 UHD TV Wall allows a HDMI 4K2K input source to be freely arranged on (4) displays (TVs or monitors) with bezel correction function.
  • Brand
    A-NeuVideo
  • SKU
    ANI-4K-VW
  • Weight
    10.00 lbs
  • Warranty
    3 Years
  • Condition
    New
  • Status
    Available
Questions? Ask our experts!

GET A QUOTE
  • $1123.20
Market price: $1295.00, you save $171.80
  • 13% less


The ANI-4K-VW 1x4 UHD TV Wall allows a HDMI 4K2K input source to be freely arranged on (4) displays (TVs or monitors) with bezel correction function. The friendly control application for the TV Wall system has never been easier. This application leads the user through single or total device control.The device supports video output timings up to WUXGA@60RB and 1080p@60Hz, audio formats up to 7.1CH LPCM at 192kHz sampling rate based on the input source EDID. All the operation and control can be done through Telnet and RS-232.

Features:

  • HDMI with 4K2K supported, HDCP and DVI compliant
  • Output source signal to (4) displays as a full image with adjustable Bezel correction
  • Supports Input PC resolutions from VGA~WUXGA and HDTV from 480i~1080p and 4K2K@24/25/30Hz
  • Supports different input and output resolutions selectable from the TV wall application
  • Supports AC3/DTS/Dolby Digital Plus/Dolby TrueHD/Dolby Atmos and DTS-HD Master Audio
  • Supports RS-232 and Telnet controls
  • Video Bandwidth: 300MHz/9Gbps
  • Input Ports: 1x HDMI (Female type), 1x Control (RJ45), 1x RS-232 (D-sub 9-pin), 1x USB (Service only)
  • Output Ports: 4x HDMI (Female type)
  • HDMI Cable Distance: ~32 ft/10M 8-bit 1080p, ~16ft/5M 4K2K
  • IR Frequency: 30~50kHz
  • Baud Rate: 115200bps
  • ESD Protection Human body model:
  • ± 8 kV (air-gap discharge)
  • ± 4 kV (contact discharge)
  • Power Supply: 12 V/3 A DC (US/EU standards, CE/FCC/ULcertified)
  • Dimensions (WxDxH): 17.2 x 10.6 x 1.7 in (438x269x44mm) (Jacks Excluded)/ 20 x 10.8 x 2 in (482x274x52mm) (Jacks Included)
  • Weight: 6.5 lb/2956g
  • Chassis Material: Metal
  • Color: Black
  • Operating Temperature: 0˚C~40˚C / 32˚F~ 104˚F
  • Storage Temperature: −20˚C~60˚C / −4˚F~140˚F
  • Relative Humidity: 20~90 % RH (non-condensing)
  • Power Consumption: 12.98W
